Quick Details
-
Brand Name:
-
JSN
-
Model Number:
-
JSN-CHL
-
Place of Origin:
-
Shanghai, China
-
Outlet Size:
-
25mm/50mm
-
Power:
-
0.37kW-3KW
-
Product name:
-
Stainless steel multi-stage booster water pump
-
Usage:
-
Booster
-
Material:
-
Stainless Steel
-
Keywords:
-
Automatic Water Pump
-
Fuel:
-
AC Electric Induction Motor
-
Feature:
-
High Efficiency
-
Name:
-
Hot Water Circulation Pump
-
Type:
-
Circulating Pumps
-
Pump Type:
-
Self-priming Water Pump
Quick Details
-
Application:
-
Biofuel Industry, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Machining, Metal and Equipment Manufacturers, Mining industry, Pharmaceutical industry, Raw Water Intake, temperature control, Washing and Cleaning, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions
-
Pressure:
-
Ultra High Pressure
-
Voltage:
-
220/380V
-
Brand Name:
-
JSN
-
Model Number:
-
JSN-CHL
-
Place of Origin:
-
Shanghai, China
-
Outlet Size:
-
25mm/50mm
-
Power:
-
0.37kW-3KW
-
Product name:
-
Stainless steel multi-stage booster water pump
-
Usage:
-
Booster
-
Material:
-
Stainless Steel
-
Keywords:
-
Automatic Water Pump
-
Fuel:
-
AC Electric Induction Motor
-
Feature:
-
High Efficiency
-
Name:
-
Hot Water Circulation Pump
-
Type:
-
Circulating Pumps
-
Pump Type:
-
Self-priming Water Pump
Products Description
About this item
The CHL type self priming jet pump series electric pump is an ideal new type of efficient and energy-saving household water pump,widely used for household water intake, underground water pumping, tap water pressurization, circular forest irrigation, vegetable greenhouse water supply, industrial and mining enterprises, and breeding industries
|
Technical Parameter
|
|
|
|
Product Name
|
Stainless Steel Variable Frequency Booster Pump Multi-stage Centrifugal Home and Commercial Constant Voltage Hot Water Pump
|
|
|
Material
|
Stainless Steel
|
|
|
Flow range
|
2~20 m³/h
|
|
|
Rated power
|
0.37KW-3KW
|
|
|
Rated head
|
15-50m
|
|
|
rated voltage
|
220V/380V
|
|
|
Pressure
|
High Pressure
|
|
|
Outlet Size
|
25mm/50mm
|
|
Usage conditions:
1. The liquid temperature of the transported water source is less than+40 ° C;
2. The pH value is between 6.5 and 8.5;
3. The volume ratio of solid impurities in water shall not exceed 0.1%; The particle size shall not exceed 0.2mm;
4. The power frequency is 50Hz, the voltage is single-phase 220V, and the voltage fluctuation range is 0.9-1.1 times the rated value;
Product Show
Specification
|
Performance Table
|
Model
|
Motor(KW)
|
Q(m³/h)
|
1
|
2
|
3
|
4
|
5
|
6
|
|
|
CHL4-2
|
0.37
|
|
19
|
18
|
17
|
15
|
12.5
|
10
|
|
|
CHL4-3
|
0.55
|
|
28
|
27
|
26
|
23.5
|
20.5
|
17
|
|
|
CHL4-4
|
0.75
|
|
37.5
|
36
|
34
|
31
|
27
|
23
|
|
|
CHL4-5
|
1.1
|
|
47
|
45
|
42.5
|
39
|
34
|
29
|
|
|
CHL4-6
|
1.1
|
|
56
|
54
|
51
|
47
|
41.5
|
35.5
|
|
8
(T)
Performance Table
|
Model
|
Motor(KW)
|
Q(m³/h)
|
5
|
6
|
7
|
8
|
9
|
10
|
|
|
CHL8-2
|
0.75
|
|
20
|
19.5
|
19
|
18
|
17
|
15.5
|
|
|
CHL8-3
|
1.1
|
|
29.5
|
29
|
28
|
27
|
25
|
23
|
|
|
CHL8-4
|
1.5
|
|
39
|
38
|
37
|
35
|
33
|
30.5
|
|
|
CHL8-5
|
2.2
|
|
51
|
49.5
|
47.5
|
45
|
42.5
|
39.5
|
|
12
(T)
Performance Table
|
Model
|
Motor(KW)
|
Q(m³/h)
|
7
|
8
|
9
|
10
|
11
|
12
|
|
|
CHL12-1
|
0.75
|
|
11.5
|
11.2
|
11
|
10.5
|
10
|
9.5
|
|
|
CHL12-2
|
1.1
|
|
23
|
22.5
|
22
|
21.5
|
20.5
|
19.5
|
|
|
CHL12-3
|
1.5
|
|
35
|
34.5
|
33.5
|
32.5
|
31
|
29.5
|
|
|
CHL12-4
|
2.2
|
|
47
|
46
|
45
|
43.5
|
41.5
|
39.5
|
|
|
CHL12-5
|
3
|
|
60
|
58
|
56.5
|
55
|
52.5
|
50
|
|
16
(T)
Performance Table
|
Model
|
Motor(KW)
|
Q(m³/h)
|
8
|
10
|
12
|
14
|
16
|
18
|
|
|
CHL16-2
|
2.2
|
|
26
|
25
|
24
|
23
|
21.5
|
20
|
|
|
CHL16-3
|
3
|
|
40
|
39
|
38
|
36
|
34
|
31.5
|
|
20
(T)
Performance Table
|
Model
|
Motor(KW)
|
Q(m³/h)
|
10
|
12
|
14
|
16
|
18
|
20
|
|
|
|
|
|
27
|
26.5
|
25.5
|
25
|
23.5
|
22
|
|
|
|
|
|
39.5
|
39
|
38
|
37.5
|
35.5
|
34
|
