Quick Details
-
Warranty:
-
30Years
-
Brand Name:
-
JHD
-
Model Number:
-
JHD-144MH
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
2278*1134*30mm
-
No. of cells:
-
144(12*12)
-
Weight:
-
28.40KG
-
Front Glass:
-
3.2mm HighTransmission,Tempered Glass
-
Frame:
-
Anodized Aluminium Alloy(Sliver/Black)
-
Maximum system Voltage:
-
1500V
-
Maximum Series Fuse Rating:
-
25A
-
Junction Box:
-
IP68 3 Diodes
-
Output Cables:
-
4mm^2 Cable 90cm(Including MC4 Connector)
-
Maxwind Load/Snow Load:
-
2400Pa/5400Pa
-
20FT Container/40HQ Container:
-
5Packages/185PCS;20Packages/740PCS
Quick Details
-
Cell size:
-
182*91 N-type Mono
-
Type:
-
N-TYPE
-
Panel Efficiency:
-
21-24%
-
Warranty:
-
30Years
-
Brand Name:
-
JHD
-
Model Number:
-
JHD-144MH
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
2278*1134*30mm
-
No. of cells:
-
144(12*12)
-
Weight:
-
28.40KG
-
Front Glass:
-
3.2mm HighTransmission,Tempered Glass
-
Frame:
-
Anodized Aluminium Alloy(Sliver/Black)
-
Maximum system Voltage:
-
1500V
-
Maximum Series Fuse Rating:
-
25A
-
Junction Box:
-
IP68 3 Diodes
-
Output Cables:
-
4mm^2 Cable 90cm(Including MC4 Connector)
-
Maxwind Load/Snow Load:
-
2400Pa/5400Pa
-
20FT Container/40HQ Container:
-
5Packages/185PCS;20Packages/740PCS
| Peak Power | 550W | 555W | 560W | 565W | 570W | 575W | 580W |
| Max Power Valtage | 41.50 | 41.64 | 41.77 | 41.92 | 42.07 | 42.22 | 42.37 |
| Max Power Current | 13.26 | 13.33 | 13.41 | 13.48 | 13.55 | 13.62 | 13.69 |
| Open Circuit Voltage(%) | 50.21 | 50.34 | 50.47 | 50.60 | 50.74 | 50.88 | 51.06 |
| Short Circuit Current (%) | 14.00 | 14.07 | 14.15 | 14.23 | 14.31 | 14.39 | 14.46 |
| Module Efficiency | 21.29 | 21.48 | 21.68 | 21.87 | 22.07 | 22.26 | 22.45 |
| Power Tolerance | 0-3W | ||||||
| Pmax Temperature Coefficients | -0.3%/ ℃ | ||||||
| Voc Temperature Coefficients | -0.25%/ ℃ | ||||||
| Isc Temperature Coefficients | +0.046%/ ℃ | ||||||
| NOCT Nominal Operating Cell Temperature | 45 ℃ | ||||||
| Operating and Storage Temperature | -40-85 ℃ | ||||||
| Standard Test Condition | 1000W/M^2,AM1.5;25+/-2 ℃ | ||||||
What is the conversion efficiency of the solar panels?
The conversion efficiency of monocrystalline silicon photovoltaic panels is generally 15-22%, and the conversion efficiency of photovoltaic panels we produce can reach more than 21%, which is the leading level in the industry.
What is the rated power output?
The specific rated power is introduced in the product details, or you can consult our salesman.
Who is the manufacturer of the solar panels?
We are a professional photovoltaic panel manufacturer, with the most advanced production line and production technology, and the raw materials are from Longji, Jinko, JA,GCL,Canadian Solar and other industry leading enterprises, you can fully trust the quality of our products.
Has the product obtained relevant certifications, such as CE, TÜV, etc.?
All our products have passed the relevant certification, the specific certificate can be obtained by contacting our salesman.
What is the warranty period for the product?
Our products are guaranteed for 30 years.
Under what environmental conditions are the solar panels suitable?
Our product quality is excellent and reliable, in a variety of harsh environments are able to run perfectly, and do the industry-leading dustproof and waterproof level.
Can they be applied to different types of buildings?
We have a professional team of engineers, can be tailored to suit your installation program.
Are they suitable for off-grid or grid-tied systems?
Our products support off-grid, grid-connected and mixed-network.
Is professional installation necessary?
Photovoltaic panels are best carried out under the guidance of professionals. If you do not have professional installers, you can also contact us. We have a team of professional engineers who can provide technical support.
Does maintenance require specialized skills?
For the service life of photovoltaic panels, it is recommended that you regularly ask professionals to conduct a comprehensive inspection and maintenance of your photovoltaic panels.
Is the production process of the solar panels environmentally friendly?
We are a company that pays attention to ecological sustainable development. We have strict production processes and standards in the production process, which will not have any impact on the environment. You can rest assured to buy our products.
