Quick Details
-
Model Number:
-
UD-6
-
Brand Name:
-
MIT-UNID-CNS
-
Pipe Size:
-
Pipe diameter is 1/8 ", 1/4", 3/8 ", 1/2"
-
Orifice:
-
2.5mm
-
Fluid Temp:
-
Standard:-5~80℃,Option:-5~130℃
-
Control Mode:
-
Normally Closed
-
Valve Body:
-
Forged brass
-
Voltage:
-
DC:12V,24V,36V;AC:24V,36V,110V,220V,380V,440V
-
Operating Pressure:
-
0-7Bar
-
Applicable Fluid:
-
Standard:Water,Air,Light Pil,Optional:Vacuum,Gas
-
Certificate:
-
CE,CSA
Quick Details
-
Port Size:
-
1/8''
-
Warranty:
-
1 year
-
Place of Origin:
-
CHN
-
Model Number:
-
UD-6
-
Brand Name:
-
MIT-UNID-CNS
-
Pipe Size:
-
Pipe diameter is 1/8 ", 1/4", 3/8 ", 1/2"
-
Orifice:
-
2.5mm
-
Fluid Temp:
-
Standard:-5~80℃,Option:-5~130℃
-
Control Mode:
-
Normally Closed
-
Valve Body:
-
Forged brass
-
Voltage:
-
DC:12V,24V,36V;AC:24V,36V,110V,220V,380V,440V
-
Operating Pressure:
-
0-7Bar
-
Applicable Fluid:
-
Standard:Water,Air,Light Pil,Optional:Vacuum,Gas
-
Certificate:
-
CE,CSA
About Us
Products Description
|
Model
|
|
UD-6
|
|
|
|||
|
Pipe Size
|
|
Pipe diameter is 1/8 ", 1/4", 3/8 ", 1/2"
|
|
|
|||
|
Control Mode
|
|
Normally Closed
|
|
|
|||
|
Valve Body
|
|
Forged brass
|
|
|
|||
|
Conncetion
|
|
Thread,Standard:BSPT,Optional:BSP,NPT
|
|
|
|||
|
Voltage
|
|
DC:12V,24V,36V;AC:24V,36V,110V,220V,380V,440V
|
|
|
|||
|
Fluid Temp
|
|
Standard:-5～80℃,Optional:-5～130℃
|
|
|
|||
|
Operating Pressure
|
|
0-7Bar
|
|
|
|||
|
Feature
|
|
Direct-acting,Able to be Operated without Pressure
|
|
|
|||
|
Applicable Fluid
|
|
Standard:Water,Air,Light Pil,Optional:Vacuum,Gas
|
|
|
|||
|
Certificate
|
|
CE,CSA
|
|
|
|||
