Quick Details
-
Interface:
-
Ethernet, RJ45 Cat6
-
Data rate:
-
10/100/1000Mb/s
-
Line voltage:
-
60V
-
Operating Voltage:
-
POE 75V
-
Max surge discharge current:
-
5KA(8-20μs)
-
Protected pins:
-
All pins
-
Mounting:
-
Grounding clip & Grounding terminal
-
Shell material:
-
ABS
-
Size:
-
26*26*95mm
-
Weight:
-
52g
Quick Details
-
Brand Name:
-
SY
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
SY3160
-
Interface:
-
Ethernet, RJ45 Cat6
-
Data rate:
-
10/100/1000Mb/s
-
Line voltage:
-
60V
-
Operating Voltage:
-
POE 75V
-
Max surge discharge current:
-
5KA(8-20μs)
-
Protected pins:
-
All pins
-
Mounting:
-
Grounding clip & Grounding terminal
-
Shell material:
-
ABS
-
Size:
-
26*26*95mm
-
Weight:
-
52g
SY3160 network electrical rj45 thunder surge protector arrester 5ka spd
1. Specifications Details
| Type | SY3160 |
| Connection | Ethernet RJ45 Cat6 with POE |
| Data rate | 10/100/1000Mb/s |
| Line voltage | 60V |
| Max continuous operationg voltage | POE 75V |
| Max surge discharge current | 5KA(8 to 20 μ s) |
| Protected pins | All pins |
| Mounting | Grounding clip & Grounding terminal |
| Shell material | ABS |
| Dimensions | 26*26*95mm |
| Package inch | 40*26*105mm |
| Weight | 52g |
2.Dimensions
3.Main feature:
--ABS material profile shell, attractive and durable, good shielding effect;
--RJ 45, convenient to use, reliable connection;
--Introducing multilayer protection circuit, selecting the latest high-speed surge protection device of quick response, low output residual voltage and super transmission performance.
4.Package
Surge protector x 1
Grounding terminal/Grounding clip x 1
Manuals/Instructions x 1
5.Certificates
CE certificate
Compliant to ROHS
Lead-free
6.Service
A.OEM, small order accepted
B. If there is other requirements, pls send us your specs, thanks!
Welcome your inquiry, we will do our best to support you!
