Quick Details
-
Color:
-
white grey or customized
-
Door:
-
Steel Security Door
-
Window:
-
PVC Sliding Window or customized
-
Floor:
-
18mm Fiber Cement Board
-
Ceiling:
-
integrated color steel sheet
-
Roof:
-
Sandwich Panel+ Decoration Ceiling
-
Size:
-
L 6055mm* W 2435*H 2896
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
DONGCHUANG
-
Wall:
-
Sandwich Panel Wall
-
Color:
-
white grey or customized
-
Door:
-
Steel Security Door
-
Window:
-
PVC Sliding Window or customized
-
Floor:
-
18mm Fiber Cement Board
-
Ceiling:
-
integrated color steel sheet
-
Roof:
-
Sandwich Panel+ Decoration Ceiling
-
Size:
-
L 6055mm* W 2435*H 2896
Products Description
|
Container House Parameters
|
|
|
||
|
Size
|
L 6055mm* W 2435*H 2896
|
|
||
|
Life span
|
More than 20 years
|
|
||
|
Steel Frame |
Main Beam For Floor And Bottom
|
Galvanized formed beam
|
||
|
|
|
Thickness:3.0mm,2.5mm,2.3mm
|
||
|
|
Top Frame |
C shape steel:C80*1.3mm,galvanized
|
||
|
|
|
Square tube: 20*20*1.0mm,galvanized
|
||
|
|
|
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³
|
||
|
|
Bottom Frame |
Square tube: 50*100*1.2mm,galvanized
|
||
|
|
|
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³
|
||
|
|
Column
|
Galvanized steel Column
|
||
|
|
|
Thickness:3.0mm,2.5mm,2.3mm
|
||
|
|
Corner fitting
|
Galvanized steel
|
||
|
|
|
Thickness:3.5mm
|
||
|
Wall system
|
75mm Sandwich Panel
|
75mm rock wool board,density≥80kg/m3
|
||
|
Floor |
Fiber Cement Board
|
Thickness :18mm
|
||
|
|
Vinyl flooring
|
Thickness:1.6mm/2.0mm
|
||
|
Roof
|
Ceiling
|
V-831 type,0.4mm Integrated Color Steel Sheet
|
||
|
Window
|
Sliding Window
|
925mm*1100mm
|
||
|
Door
|
Steel Security Door
|
840mm*2035mm
|
||
|
Electrical Device |
CEE industrial plug, socket voltage 220V- 250V, 2P32A, Fixed in explosion-proof box at the top beam of the short side; Using IP44
standard power distribution box. |
|
||
|
|
main power cable is 6 mm², AC cable is 4 mm², socket cable is 2.5 mm², lighting & switch cable is 1.5 mm².
Four sockets, 1pc AC socket of three holes 16A, 3pcs socket of five holes 10A. 1pc single connection switch, 2pcs LED light, 2*15W. |
|
||
|
Accessories
|
Screw ,Blot, Silicon sealant,etc
|
|
||
OUR ADVANTAGES
|
ADVANTAGES
|
|
1 Fast installation four workers can install one unit within two hours
|
|
2 . Environmental protection , can be reused many times and no construction waste
|
|
3 . Durable , service life up to 30 years
|
|
4.Heat insulation, windproof, shockproof, moisture-proof, waterproof, leakage proof, environmental protection, reliable, fast and easy to be moved, flexible combination.
|
|
5 . Modular building , Can be used in office building , workers dormitories , hotels , hospitals , warehousing,classrooms etc
|
PRODUCT DEATILS
INSTALLATION PROCESS
PRODUCTION PROCESS
