Quick Details
-
Product name:
-
leaching equipment
-
Groove capacity:
-
1.5 L/3L/5L
-
Impeller Diameter:
-
31/39/48mm
-
Rotary speed of impeller:
-
0-2800rpm(Adjustable)
-
Usage:
-
wet-process leaching test
-
Application:
-
geology/metallurgy/building material/chemicals
-
Voltage:
-
220V
-
Temperature:
-
0-100 ℃ (Adjustable)
-
Dimension(L*W*H):
-
340*505*633
Quick Details
-
Weight (KG):
-
43
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
-
-
Product name:
-
leaching equipment
-
Groove capacity:
-
1.5 L/3L/5L
-
Impeller Diameter:
-
31/39/48mm
-
Rotary speed of impeller:
-
0-2800rpm(Adjustable)
-
Usage:
-
wet-process leaching test
-
Application:
-
geology/metallurgy/building material/chemicals
-
Voltage:
-
220V
-
Temperature:
-
0-100 ℃ (Adjustable)
-
Dimension(L*W*H):
-
340*505*633
Product Overview
Laboratory Leaching Tank
XJT-II laboratory leaching tank
is a heat-controlled with agitator and designed for leaching and agitating slurries. It is compact and of rugged construction for general laboratory or small pilot plant operations. Perfect for gold, silver cyanidation tests, or copper acid leach tests.
This hydrometallurgy test unit is a multi-functional air-injected leach tank reactor with a built-in air pump with the controllable flow and a variable speed agitator/heater.
Permits agitated leach tests at agitator speeds of 0 to 2800 RPM. Uses a digital display for accurate adjustment. Built-in thermometer which displays the temperature of slurry undergoing leaching.
1-year-warranty
Built-in 250 Watt heater and temperature controller (50 Celsius) for your leach slurry.
Comes standard with 1.5 liter, 3 litre and 5 liter
acrylic
leach tanks.
Three (3) size agitators of 31 mm, 39 mm and 48 mm diameter are included with the laboratory leaching tank.
PRODUCT SPECIFICATIONS
|
Cell Capacity
|
L
|
1.5/3/5
|
|
Rotary Speed of Impeller
|
r/min
|
0-2800(adjustable)
|
|
Motor
|
W
|
120
|
|
Impeller Diameter
|
mm
|
31/39/48
|
|
Dimension
|
mm
|
340*505*633
|
|
Weight
|
kg
|
40
|
|
Voltage
|
V
|
220
|
FEATURES AT A GLANCE
Right elevation
Left elevation
Front elevation
Details Images
Product packaging
