Quick Details
-
Model Number:
-
JF18R90-M5
-
material:
-
ceramic
-
use:
-
faucet
-
material2:
-
brass
-
color:
-
slive
-
size:
-
1/2 3/8 3/4
-
weight:
-
20-120g
Quick Details
-
Material:
-
Ceramic
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Jintong
-
Model Number:
-
JF18R90-M5
-
material:
-
ceramic
-
use:
-
faucet
-
material2:
-
brass
-
color:
-
slive
-
size:
-
1/2 3/8 3/4
-
weight:
-
20-120g
We mainly produce metal products,brass cartridges,
faucet fittings,brass valves, angle valves, PP-R pipe fittings and sanitary ware.
We already have 20 years of operational experience,
strong technical force and a sophisticated marketing system
Technique index¶meter
◊Usage elucidation
|
Max. turn angle |
90° |
Max. temperature |
90° |
|||||||||||||
|
Relation between pressure and flow rate |
||||||||||||||||
|
Pressure(Mpa) |
0.05 |
0.1 |
0.15 |
0.2 |
0.25 |
0.3 |
0.35 |
0.4 |
0.45 |
0.5 |
||||||
|
Average flow rate |
16.8 |
22.9 |
28.0 |
32.5 |
36.0 |
38.7 |
40.6 |
42.4 |
43.3 |
47.6 |
||||||
|
Fitting method |
Screw connecting G3/4 " |
|||||||||||||||
◊Performance test
|
The strength test |
Static pressure 3.5Mpa |
Torque test |
≥15Nm |
||
|
Left and right rotation torque Nm when static pressure is zero |
0.15-0.25Nm |
||||
|
Sealing test |
Static pressure |
Air |
High pressure |
1.0Mpa |
|
|
Low pressure |
0.02Mpa |
||||
|
Cold water |
High pressure |
2.5Mpa |
|||
|
Low pressure |
0.05Mpa |
||||
|
Dynamic pressure |
0.3Mpa |
||||
|
Life test |
500,000 open and close cycles |
||||
◊Ceramics
|
Technique requestment of ceramics |
||||
|
Sealing face of ceramic disc |
Hardness |
≥1050HV5 |
Roughness |
≤Ra0.2um |
|
Flatness (light band) |
||||
Precise & reliable components:
Net weight by accurate electronic scale:
