outdoor function tents, workshop tent, work tent

Quick Details

Place of origin : Guangdong, China (mainland)

Brand name : Smart Tent

Certifications : ISO 9001:2008, CE, TUV

Shapes : pagoda, gable, hexagonal, curve dome …… customization is welcome.

Colors: silver, white, blue, red ……

Sidewalls : Soft PVC walls, glass wall, ABS hard ……

Windows: clear PVC

Max. Allowed Wind Speed : 80 KM/H

Snow load : 75 KG/ SQ. M.

Service Life: over 10 years

Ground Situations : grassland, earth land, asphalt cement ……

Fixing solutions : ground anchor, expandable bolt ……

Materials:

u Frames : high-strength aluminum alloy 6601/T6 (tensile intensity: 290MPa; yield strength: 270Mpa.0.)

u Covers : 1) double side PVC-coated fabric.

l Thickness of cloth: 0.76mm.

l Weight of cloth: 850g/square meters;

l Tensile strength: longitude 3553N/5cm, latitude 2939N/5cm.

l Tearing strength: Longitude 462/N, latitude 348/N.

l Peeling strength: Longitude 118N/5cm, latitude 116/5cm.

l Temperature resistance ( ℃): -30 ℃ -70 ℃ .

2) UV resistant; water-proof, fire retardant, self-cleaning ability;

3) up to DIN4102 B1,M2 standard.

4) Color optional; logo printing available.

u Stents of covers : high-strength aluminum alloy 6601/T6, which are in good quality and never rusty.

Specifications :

Clear Span	Bay width	Min. Length	Max. length	Ridge Height	Eave Height	Roof Slop	Longest Component
meter	meter	meter	meter	meter	meter	°	meter
8.00	3.00/5.00	6.00	unlimited	3.85	2.50	20.00	4.20
9.00	3.00/5.00	6.00	unlimited	4.10	3.00	20.00	4.90
10.00	3.00/5.00	10.00	unlimited	4.30	3.00	20.00	5.40
15.00	5.00	10.00	unlimited	5.50	3.00	18.00	8.00
20.00	5.00	20.00	unlimited	7.20	4.00	18.00	10.70
21.00	5.00	20.00	unlimited	7.40	4.00	18.00	11.30
25.00	5.00	25.00	unlimited	8.00	4.00	18.00	13.25

l Clear span: 3m, 4m, 5m, 6m, 8m, 9m, 10m (refer to medium or large tents for larger size)

l Length: 3m, 6m, 9m,12m and + 3m more ( no limitation) or 5m, 10m, 15m+5m more (no limitation)

l Flexibility: The tents not only have standard modular sizes for construction, but also can achieve customized requirements.

Installation Drawing:

Certifications:

Applications :

Our tents are used for the most varied event formats:  parties, exhibitions, weddings, celebrations, sports events, promotions, meetings, concerts, emergency rescue, industrial semi-permanent storage, temporary warehouse or workshops, military affairs, shelter, etc.

Accessories available:

u Sidewalls: PVC sidewalls with transparent windows, glass wall, ABS hard wall, sandwich wall.

u Doors: double- swings glass doors, sliding glass doors, rolling doors, etc..

u PVC transparent window, opaque/transparent/colorful PVC cover

u Rain gutters: inner roof bean rain gutters or rain gutters between to tents)

u Interior decorations:

l Lighting: down lights, globe lanterns, etc.

l Air conditioner: 5P cabinet air conditioners, Ceiling air conditioners, central air conditioning duct system, etc.

l Tables & chairs: A wide range of tables for you to choose: round tables, square tables, long tables, beer tables, folding chairs, ordinary chairs and luxury chairs, etc.

l Curtains

u Wooden flooring system, stage truss, carpet, mobile toilet, loading platform , etc

u Fixing devices: steel nail, expandable screw ( for concrete ground), anchors ( for grass land or asphalt ) ,weight plate etc.

Our advantages:

1) Easy to be assembled and dismantled.

2) Movable

3) NO pole inside, 100% available interior space.

4) Competitive price (China mainland manufacturer)

5) Various types for selection

6) Prompt delivery

7) OEM, ODM orders are acceptable

8)   Professional installation services if needed

9)   Life long free technial advice
