Quick Details
-
H.S.Code:
-
5431499900
-
Application:
-
Rubber track chassis used for lawn mower, snowblower etc
-
Product name:
-
Rubber track chassis undercarriage platform
-
Material:
-
Rubber&alloy aluminum frame
-
Production capacity:
-
1000pcs/month
-
Package:
-
Plywood Box
-
Delivery:
-
5-15 working Days
-
Color:
-
Black or as per customer's demand
Quick Details
-
Place of Origin:
-
Shanghai, China, Shanghai,China
-
Brand Name:
-
KCM
-
Minimum Order Quantity::
-
1 Piece
-
H.S.Code:
-
5431499900
-
Application:
-
Rubber track chassis used for lawn mower, snowblower etc
-
Product name:
-
Rubber track chassis undercarriage platform
-
Material:
-
Rubber&alloy aluminum frame
-
Production capacity:
-
1000pcs/month
-
Package:
-
Plywood Box
-
Delivery:
-
5-15 working Days
-
Color:
-
Black or as per customer's demand
We can customize various tracked undercarriage systems and the load capacity is from 0.5 ton to 20 ton. It has been widely applied in drilling machines (core drill, horizontal directional drilling rig, belt engineering drill, and engineering rig), engineering machines, mining, colliery, agricultural and gardening machines. Meanwhile, we have a lot of experience engineers who can provide you technical support and professional consultation .
Below is our small size, for big size,please kindly contact us
|
Small size rubber track undercarriage chassis platform |
|||||||||
|
Model |
Length |
Width |
Height |
Sprocket Diameter |
Rubber Track Model/ Width |
Rubber Track Link |
Weight |
Load-bearing Weight |
fr ame |
|
KCM -40 |
540mm |
545mm |
150mm |
140mm |
40/40mm |
27 |
26.5kg |
50kg |
Aluminum Alloy Bracket |
|
KCM- 50 |
810mm |
377mm |
165mm |
99mm |
KCM DG-50/50mm |
75 |
50kg |
100kg |
Stainless Steel Bracket |
|
KCM -76 |
940mm |
550mm |
210mm |
200mm |
KCM -A/76mm/ KCM -B/60mm |
138/84 |
24.15kg |
150kg |
Aluminum Alloy Box |
|
KCM -100 |
700MM |
520MM |
240MM |
197MM |
KCM -A/100mm |
40 |
95kg |
100kg |
Aluminum Alloy Box |
|
KCM -70 |
590mm |
530mm |
250mm |
172mm |
KCM -70/ 70mm |
28 |
17.85kg |
100kg |
|
|
KCM -70 |
800MM |
570mm |
300mm |
195.7mm |
KCM -70/ 70mm |
43 |
44kg |
150kg |
Aluminum Alloy Box |
|
KCM -70 |
1010MM |
540mm |
410mm |
195.7mm |
KCM -70/ 70mm |
54 |
106kg |
150kg |
Aluminum Alloy Box |
|
KCM -100 |
640mm |
520mm |
260mm |
212mm |
KCM -A/ 100 mm |
36 |
46kg |
75kg |
Square Tube Bracket |
