Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Shinestraw
-
Voltage:
-
by required
-
Dimension(L*W*H):
-
1900*1580*1380mm
-
Weight:
-
1080 kg
-
Marketing Type:
-
New Product
-
Product name:
-
paper slitter machine
-
Function:
-
Slitting Rewinding JUMBO Paper Roll
-
Max.cutting width:
-
620mm
-
Max. Unwinding Diameter:
-
1000mm
-
Max.Rewinding Diameter:
-
550-600mm
-
Min cutting width:
-
13.5mm
-
Speed:
-
80-100m/min
-
Precision:
-
±0.10mm
-
Power Supply:
-
2.2kw---4kw
Quick Details
-
Type:
-
Slitting Rewinder
-
Production Capacity:
-
100%
-
Max. workable width:
-
1000mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Shinestraw
-
Voltage:
-
by required
-
Dimension(L*W*H):
-
1900*1580*1380mm
-
Weight:
-
1080 kg
-
Marketing Type:
-
New Product
-
Product name:
-
paper slitter machine
-
Function:
-
Slitting Rewinding JUMBO Paper Roll
-
Max.cutting width:
-
620mm
-
Max. Unwinding Diameter:
-
1000mm
-
Max.Rewinding Diameter:
-
550-600mm
-
Min cutting width:
-
13.5mm
-
Speed:
-
80-100m/min
-
Precision:
-
±0.10mm
-
Power Supply:
-
2.2kw---4kw
|
Model |
SS450 |
SS600 |
|
Sitting speed |
80- 100 m/min |
80- 100 m/min |
|
Blades number |
3 3 pcs for 1 3.5 /14mm 3 5 pcs for 15mm |
4
5 pcs for
1
3.5 /14mm
4 2 pcs for 15mm |
|
Rewinding wallboard |
Single side |
Both sides |
|
A uto loading cylinder |
1 00*100 500kg |
1 00*100 500kg |
|
Max width of web |
4 5 0 mm |
6 4 0 mm |
|
Max unwinding diameter |
95 0 mm |
1 000mm |
|
Max rewinding diameter |
55 0 mm |
550-600mm |
|
Min cutting width |
13.5 mm |
1 3.5mm |
|
Max cutting width |
450 m m |
6 20mm |
| Positioning precision |
± 0.10 mm |
± 0.10 mm |
| Main motor power |
2.2 kw |
4 kw |
|
Overall size |
1700*1280*1380 m m |
1900*1580*1380 m m |
|
Weight |
880 kg |
9 60kg |
