Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
AIBEIKEN
-
Model Number:
-
PS25B-PNOF-D/S
-
Product Name:
-
Underwater Push Button Switch
-
Mounting Hole Size:
-
25mm
-
Operation Type:
-
Momentary
-
Head Type:
-
Flat Head
-
Enclosure Material:
-
Stainless Steel
-
Terminal Type:
-
300mm Long 26AWG
-
Life Expectancy:
-
50 Million cycles
-
Operating Temperature:
-
-40°C ~+75°C
-
Accessories:
-
Nut, Rubber Waterproof O-ring
Quick Details
-
Protection Level:
-
IP68
-
Max. Current:
-
2A
-
Max. Voltage:
-
24V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
AIBEIKEN
-
Model Number:
-
PS25B-PNOF-D/S
-
Product Name:
-
Underwater Push Button Switch
-
Mounting Hole Size:
-
25mm
-
Operation Type:
-
Momentary
-
Head Type:
-
Flat Head
-
Enclosure Material:
-
Stainless Steel
-
Terminal Type:
-
300mm Long 26AWG
-
Life Expectancy:
-
50 Million cycles
-
Operating Temperature:
-
-40°C ~+75°C
-
Accessories:
-
Nut, Rubber Waterproof O-ring
Electric Water Lighting Dot Blue Led 12V 24V Illuminated Sealed Piezoelectric Underwater Push Button Switch
Product description:
Install diameter : 25mm hole diameter
Rated current : 2A
Rated voltage : 24V
Crust Material :Stainless steel 316L
Crust color: Stainless steel
LED COLOR: Blue(Red, Green, Yellow, White, Purple, Bi-color, Tri-color available)
LED Voltage:12V (or 3V/5V/6V/24V)
IP rated : IP68
Life : 50 Million
Operation force: 6 to 15 (N)
Operation temperature: - 40 to +75 degree
|
Product Name |
IP68 Waterproof Piezo Switch |
|
Model |
PS25B-PNOF-D/S |
|
Mounting Hole |
25mm |
|
Operation Type |
Momentary (Reset) |
|
Switch Combination |
1NO |
|
Actuator Shape |
Chamfer Round Head |
|
Cable Length |
300mm long |
|
Current |
2A |
|
Led Voltage |
12V (or 3V/5V/6V/24V) |
|
Led Color |
Blue (Red, Green, Yellow, White, Purple, Bi-color, Tri-color available) |
|
Illuminated Type |
Dot Led |
|
Enclosure Material |
Stainless Steel 316L (or Silver Aluminum oxidized) |
|
Operating Force |
6 to 15N |
|
Life Expectancy |
50 Million cycles |
|
Waterproof Degree |
IP68 |
|
Operating Temperature |
-40°C ~+75°C |
|
Customized colored housing or Connector |
Acceptable and with fast shipping |
|
Accessories |
Nut, Rubber Waterproof O-ring |
|
Customized Order Confirm |
1. What Led Color? 2. What Led Voltage? |
|
What You Get |
1X Piezo Switch: 25mm, Momentary, 12V Blue LED, Stainless steel |
Note: If you need Customized LED, please inform us by mail:
1. What Led Color? 2. What Led Voltage?
