Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
BODA
-
Dimension(L*W*H):
-
L2000*W1300*1800mm
-
Weight:
-
8000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support
-
Machine type:
-
tin container maker
-
Keywords:
-
tin can maker
-
Certifications:
-
CE&ISO9001
-
Cutting Speed:
-
0-59m/min
-
Thick of Iron:
-
0.15-0.5mm
-
Lengthwise slitting quantity:
-
1~6pcs
-
Power:
-
5.45kw
-
Dimensions:
-
L6650 x W3880 x H1530
-
After-Sale Service:
-
Engineers available to serve overseas
-
Certification:
-
CE&ISO9001
Quick Details
-
Application:
-
Chemical, Food, Machinery & Hardware, Medical
-
Packaging Material:
-
Metal, Paper
-
Voltage:
-
380V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
BODA
-
Dimension(L*W*H):
-
L2000*W1300*1800mm
-
Weight:
-
8000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support
-
Machine type:
-
tin container maker
-
Keywords:
-
tin can maker
-
Certifications:
-
CE&ISO9001
-
Cutting Speed:
-
0-59m/min
-
Thick of Iron:
-
0.15-0.5mm
-
Lengthwise slitting quantity:
-
1~6pcs
-
Power:
-
5.45kw
-
Dimensions:
-
L6650 x W3880 x H1530
-
After-Sale Service:
-
Engineers available to serve overseas
-
Certification:
-
CE&ISO9001
High speed Vertical Automatic Can Seamer Machine
100% Response Rate
Leak Testing Machine
100% Response Rate
2016 Hot Sale Automatic Can Body Welding Machine High Speed
100% Response Rate
High Speed Tin Can Container Maker Making Machine
This is a machine used for cutting tinplates. A whole food tin can making machine production line will need these machines as follows:
Duplex Slitter -- Welder -- Coater -- Induction Curer -- V-Type Conveyor -- (Parting Machine) -- Combination Machine -- Seamer -- (Leak Tester) -- Palletizing Machine
For more information of can making production line pls feel free to send inquiry to us .
|
High Speed Tin Can Container Maker Making Machine
|
|
|
|
|||
|
Main Parameters
|
Name
|
|
tin container making machine
|
|||
|
|
Model
|
|
GT10A
|
|||
|
|
Weight
|
kg
|
8000
|
|||
|
|
Cutting Speed
|
m/min
|
0-59
|
|||
|
|
Thick of Iron
|
mm
|
0.15-0.5
|
|||
|
|
Power
|
KW
|
5.45
|
|||
|
|
Dimensions
|
mm
|
L6650 x W3880 x H1530
|
|||
|
|
Lengthwise slitting quantity
|
pc
|
1-6
|
|||
|
|
Min. Width of the Iron Sheet After Cutting Horizontally
|
mm
|
48
|
|||
Boda Machinery
specialized in designing and producing tin can & tin lid making machine since 1992. There's more than 10,000 square meters workshop including all necessary production equipments and CNC machine centers.
Over 50 skillful technical workers and an experienced production develop team make sure all the machines are well designed and well produced. The mother company, Wise Group, occupies nearly 90,000 square meters in Zhoushan production base and 900 staff, 100 of which are professional Mechanical Engineers.
With a strong sales team and high quality machines, our business has extend widely in the world, which are highly spoken in China, Korea, India, UAE, Russia, Germany, Italy, Holland, Egypt, Mexico, etc.
|
Tin Can Making Line
|
Duplex Slitter
|
Welding Machine
|
Coating Machine
|
Induction Curer
|
V-Type Conveyor
|
Combination Machine
|
Leak Tester
|
Palletizer
|
|
Tin Lid Making Line
|
Sheet Feeding System
|
Curling Machine
|
Lining Machine
|
Drying Machine
|
Stacker
|
|
|
|
|
Tin Can Type
|
Paint Can
|
Aerosol Can
|
Food Can
|
Beverage Can
|
Milk Powder Can
|
2-Piece Can
|
Square Can
|
Composite Can
|
|
Tin Lid Type
|
Bottom Lid
|
Aerosol Cone&Dome
|
Paint Ring
|
EOE
|
Easy Peel Off Lid
|
Twist Off Lid
|
Square Lid
|
Assembly Lid
|
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|
Packaging
|
|
|
|
Size
|
L6650 x W3880 x H1530
|
|
|
Weight
|
8 T
|
|
|
Packaging Details
|
The normal package is brandreth and wooden box as picture. We can also pack it according to customers special request.
|
|
