Quick Details
-
Scan Speed:
-
60fps/s
-
Place of Origin:
-
China
-
Trigger mode:
-
Button / auto scanning / touch scanning
-
Battery Size:
-
600mAh
-
Illumination:
-
LED 4000K
-
Focus:
-
Red LED 625nm
-
Scanning Angle:
-
Elevation 65° , rotation 30° , declination 55°
-
Viewing angle:
-
≥4mil
-
Depth of field:
-
Horizontal 34° , vertical 28°
-
Dimensions:
-
64.5*34.5*20.5mm
-
Weight:
-
69g
-
Storage capacity:
-
380000 bytes
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Optical Resolution:
-
4mil
-
Scan Speed:
-
60fps/s
-
Place of Origin:
-
China
-
Trigger mode:
-
Button / auto scanning / touch scanning
-
Battery Size:
-
600mAh
-
Illumination:
-
LED 4000K
-
Focus:
-
Red LED 625nm
-
Scanning Angle:
-
Elevation 65° , rotation 30° , declination 55°
-
Viewing angle:
-
≥4mil
-
Depth of field:
-
Horizontal 34° , vertical 28°
-
Dimensions:
-
64.5*34.5*20.5mm
-
Weight:
-
69g
-
Storage capacity:
-
380000 bytes
Products Description
Product Paramenters
|
Model
|
D2105
|
|
Operating System
|
Windows / iOS / Android
|
|
Decoding
|
1D: UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN
128,Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA Code, MSI/Plessy, China Postal Code, Code 32 (Italian Pharmacode), etc. |
|
|
2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Dotcode, GS1 DataBar stack etc.
|
|
Image Sensor
|
CMOS
|
|
Pixels
|
1280(H)*800(v)pixels
|
|
Illumination
|
Warm LED 4000K
|
|
Focus
|
Red LED 625nm
|
|
Scan Mode
|
Button scanning, touch scanning, auto scanning
|
|
Frame rate
|
60fps/s
|
|
Read accuracy
|
≥ 4mil@ Code39
|
|
Print contrast
|
≥ 20 %
|
|
Prompt mode
|
Red, blue and green LED lights, buzzer, vibration
|
|
Communication mode
|
2.4G: 50m, Bluetooth(HID,BLE)
|
|
|
SPP: 40 metres (open) / connected
|
|
Scanning Angle
|
Elevation 65° , rotation 30° , declination 55°
|
|
Viewing angle
|
Horizontal 34° , vertical 28°
|
|
Operating frequency
|
2.400GHz-2.480GHz ISM band
|
|
Dimensions
|
Scanner:64.5*34.5*20.5(mm)
|
|
|
Scanner+Finger Holder:64.5*40.5*46.5(mm)
|
|
Weight
|
Scanner 69g
|
|
Material
|
Shell: ABS + PC, TPU
|
|
Storage capacity
|
380000 bytes
|
|
Power
|
Charging Voltage: 5VDC ± 5%
|
|
|
Charging current: 1000mA
|
|
Firmware update
|
Computer online upgrade
|
|
Scanning distance
|
30-350mm @ UPC/EAN 13mil PCS=90%;
|
|
|
40-400mm @ QR 20mil PCS=100%
|
|
Pairing mode
|
One-to-one (optional one-to-many version)
|
|
Battery capacity
|
600mAh
|
|
Charging method
|
Wired charging, charging base charging
|
|
Charging time
|
2-3 h
|
|
Working hours:
|
8 hours (5 seconds between scans)
|
|
Certification
|
CE,ROHS, BIS, FCC
|
|
Operating temperature
|
-20℃--+ 60℃ Operating
|
|
Storage temperature
|
-40℃~+ 70℃
|
|
Drop height
|
2M
|
|
IP
|
IP54
|
|
Humidity
|
5%~95% non-condensing
|
|
Electrostatic protection
|
±8 kV (direct discharge)
|
|
Ambient brightness
|
0~100,000Lux
|
