Quick Details
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Electric
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
gree
-
Model Number:
-
GWH36QF-D3DNB4O
-
COP:
-
2.8
-
Power (W):
-
9850
-
Voltage (V):
-
220
-
Maximum Airflow Rate:
-
1400
-
Featured Function:
-
dehumidifier
-
Recommended Room Size（square feet）:
-
495-753
-
Product Name:
-
household Air Conditioner
-
Refrigerant:
-
R410a
-
Function:
-
Cooling and heating
-
Power supply:
-
220-240V/1Ph/50Hz
-
Brand:
-
gree
-
Keyword:
-
wholesale
-
Noise:
-
Under 57dB(A)
-
Feature:
-
WIFI Optional
-
Indoor Unit Dimension:
-
1350*326*253
-
Net Weight:
-
82kg
Quick Details
-
Capacity (btu):
-
＞12001
-
EER:
-
2-4
-
Type:
-
Split Wall Mounted Air Conditioners
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Electric
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
gree
-
Model Number:
-
GWH36QF-D3DNB4O
-
COP:
-
2.8
-
Power (W):
-
9850
-
Voltage (V):
-
220
-
Maximum Airflow Rate:
-
1400
-
Featured Function:
-
dehumidifier
-
Recommended Room Size（square feet）:
-
495-753
-
Product Name:
-
household Air Conditioner
-
Refrigerant:
-
R410a
-
Function:
-
Cooling and heating
-
Power supply:
-
220-240V/1Ph/50Hz
-
Brand:
-
gree
-
Keyword:
-
wholesale
-
Noise:
-
Under 57dB(A)
-
Feature:
-
WIFI Optional
-
Indoor Unit Dimension:
-
1350*326*253
-
Net Weight:
-
82kg
Product Description
Product Paramenters
|
Model
|
PMDG50W3-36BC
|
PMDG50W3-36BCH
|
|
Lomo Series Split-type Inverter
|
Cooling Only
|
Cooling and Heating
|
|
Power Supply
|
230V~60Hz~1pH
|
230V~60Hz~1pH
|
|
Power Supply Mode
|
Outdoor
|
Outdoor
|
|
Cross-sectional Area of Power Cable Conductor
|
2.5 mm2
|
2.5 mm2
|
|
Min/Max. Voltage
|
193/253 V
|
193/253 V
|
|
Cooling Capacity
|
9850 W
|
9850 W
|
|
Cooling Capacity
|
33600 Btu/h
|
33600 Btu/h
|
|
Heating Capacity
|
--
|
10140 W
|
|
Heating Capacity
|
--
|
34600 Btu/h
|
|
Cooling Power Input
|
3650 W
|
3650 W
|
|
Heating Power Input
|
--
|
3620 W
|
|
Cooling Current
|
15.5 A
|
15.5 A
|
|
Heating Current
|
--
|
15.5 A
|
|
Rated Input
|
3900 W
|
4200 W
|
|
EER
|
9.20 (Btu/h)/w
|
9.21 (Btu/h)/w
|
|
COP
|
--
|
9.56 (Btu/h)/w
|
|
Air Flow Volume
|
824/706/588/441/0 CFM
|
824/706/0/588/0/441/0 CFM
|
|
Dehumidifying Volume
|
3.50 L/h
|
3.50 L/h
|
|
Application Area
|
46-70 m2
|
46-70 m2
|
|
Indoor Unit Set Temperature Range
|
61～86 ℉
|
61～86 ℉
|
|
Indoor Unit Sound Pressure Level
|
55/50/46/37 dB (A)
|
55/50/46/37 dB (A)
|
|
Indoor Unit Dimension (W×H×D)
|
1350×326×253 mm
|
1350×326×253 mm
|
|
Indoor Unit Dimension of Carton Box (L×W×H)
|
1438×418×352 mm
|
1438×418×352 mm
|
|
Indoor Unit Nei weight/Gross weight
|
20/24.5 kg
|
19.5/24 kg
|
|
Outdoor Unit Air Flow Volume
|
4000 m3/h
|
4000 m3/h
|
|
Outdoor Unit Cooling Operation Ambient Temperature Range
|
-4～115 ℉
|
-4～115 ℉
|
|
Outdoor Unit Sound Pressure Level
|
59 dB (A)
|
61 dB (A)
|
|
Outdoor Unit Dimension (W×H×D)
|
1003×790×427 mm
|
1003×790×427 mm
|
|
Outdoor Unit Dimension of Carton Box (L×W×H)
|
1080×485×840 mm
|
1080×485×840 mm
|
|
Outdoor Unit Nei weight/Gross weight
|
62.5/67.5 kg
|
62.5/67.5 kg
|
|
Connection Pipe Length
|
7.5 m
|
7.5 m
|
|
Connection Pipe Outer Diameter of Liquid Pipe(British System Allocation)
|
1/4" inch
|
1/4" inch
|
|
Loading Quantity
( 20’ Container ) |
38 units
|
38 units
|
|
Loading Quantity
( 40’ Container ) |
78 units
|
78 units
|
|
Loading Quantity
( 40’ High Cube Container ) |
99 units
|
99 units
|
Why Choose Us
FAQ
Q:Are you a manufacturer or trading company?
A:We are a manufacturer that specialized in refrigeration equipment. Our products have abtained the CE.
Q: What kind of delivery for the product?
A: We can arrange the shipping by sea or by air.
Q: How is your after-sales service?
A: All the product is guarantee for one year.And we will supply the technical support after the warranty time. You can contact us 24 hours each day online.
Q:How can I get some samples?
A: We welcome sample order to test and check quality. We can’t offer free sample, please pay the sample and express fee.
Q: How about the packing?
A: packed in carton, can customized different logo according to customers' requirements.
If you have any other questions,you can leave us message or inquiry then we will contact you. Or you can directly call us or
sendus direct mail or fax to consult us.
A:We are a manufacturer that specialized in refrigeration equipment. Our products have abtained the CE.
Q: What kind of delivery for the product?
A: We can arrange the shipping by sea or by air.
Q: How is your after-sales service?
A: All the product is guarantee for one year.And we will supply the technical support after the warranty time. You can contact us 24 hours each day online.
Q:How can I get some samples?
A: We welcome sample order to test and check quality. We can’t offer free sample, please pay the sample and express fee.
Q: How about the packing?
A: packed in carton, can customized different logo according to customers' requirements.
If you have any other questions,you can leave us message or inquiry then we will contact you. Or you can directly call us or
sendus direct mail or fax to consult us.
