Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CHA
-
Model Number:
-
CTSMW-6/CTSJW-6
-
IP level:
-
IP65
-
Rated current:
-
50mA. 12V DC
-
insulation resistance:
-
100M Omega min.100V DC
-
contact resistance:
-
50m Omega max.
-
Operating temperature:
-
-30℃to +85℃
-
Life:
-
500,000 Cycles min
-
Dielectric strength:
-
250V AC for 1 min.
-
height:
-
3.1/3.5/3.8/4.3/4.5/5.0
-
Is it environmentally friendly?:
-
ROHS/HF
-
Handle color:
-
Blue, white, beige, transparent red
-
Name:
-
6.2*6.2mm Sealed tact switches waterproof IP 67 68 SMD switch
Quick Details
-
Protection Level:
-
IP65
-
Max. Current:
-
50mA
-
Max. Voltage:
-
12VDC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CHA
-
Model Number:
-
CTSMW-6/CTSJW-6
-
IP level:
-
IP65
-
Rated current:
-
50mA. 12V DC
-
insulation resistance:
-
100M Omega min.100V DC
-
contact resistance:
-
50m Omega max.
-
Operating temperature:
-
-30℃to +85℃
-
Life:
-
500,000 Cycles min
-
Dielectric strength:
-
250V AC for 1 min.
-
height:
-
3.1/3.5/3.8/4.3/4.5/5.0
-
Is it environmentally friendly?:
-
ROHS/HF
-
Handle color:
-
Blue, white, beige, transparent red
-
Name:
-
6.2*6.2mm Sealed tact switches waterproof IP 67 68 SMD switch
Product Description
Specification
|
Electrical Life
|
500,000 cycles min
|
|
Contact Resistance
|
100mΩ max
|
|
Insulation Resistance
|
100mΩ min. 500VDC
|
|
Dielectric Strength
|
250VAC/1 min
|
|
Storage Temperature
|
-30℃ to +80℃
|
|
Contact Arrangement
|
one pole one throw
|
|
Features
|
high life,waterproof,silica gel tact switch
|
|
Electrical Parameter
|
12VDC 50mA
|
|
Travel
|
0.6±0.2mm
|
Recommend Products
Packing & Delivery
Inner box with standard outer carton
