Quick Details
-
Color:
-
full color
-
Panel Size:
-
320mm*160mm, 320mm*160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P4
-
Specification:
-
960mm*320mm
-
Brightness:
-
6000cd/m2, 6000cd/m2, 6000cd/m2
-
pixel density:
-
62500/m2, 62500/m2
-
Lifespan (hours):
-
100000, 100000
-
Module Sizes:
-
320*160
-
Scan mode:
-
1/10scan
-
LED Package mode:
-
Nation Star SMD 1921 (3in1)
-
Pixels Density:
-
62500dots/m2
-
Warranty:
-
2years
-
Certificate:
-
CE ROHS FCC
-
Keyword:
-
Waterproof LED Display Screen Panels
-
Life span:
-
100000 Hours
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
LED VISUAL
-
Color:
-
full color
-
Panel Size:
-
320mm*160mm, 320mm*160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P4
-
Specification:
-
960mm*320mm
-
Brightness:
-
6000cd/m2, 6000cd/m2, 6000cd/m2
-
pixel density:
-
62500/m2, 62500/m2
-
Lifespan (hours):
-
100000, 100000
-
Module Sizes:
-
320*160
-
Scan mode:
-
1/10scan
-
LED Package mode:
-
Nation Star SMD 1921 (3in1)
-
Pixels Density:
-
62500dots/m2
-
Warranty:
-
2years
-
Certificate:
-
CE ROHS FCC
-
Keyword:
-
Waterproof LED Display Screen Panels
-
Life span:
-
100000 Hours
Product Description
Specification
|
No
|
Item
|
Parameter
|
|
|
||
|
1
|
Pixel Pitch
|
4mm
|
|
|
||
|
2
|
Led Package
|
Nation Star SMD 1921(3in1)
|
|
|
||
|
3
|
Pixel Density
|
62500dots/m2
|
|
|
||
|
4
|
Module Size
|
320*160mm
|
|
|
||
|
5
|
Modules resolution
|
80*40
|
|
|
||
|
6
|
Module Weight
|
0.49kg
|
|
|
||
|
7
|
Scan Mode
|
1/10s
|
|
|
||
|
8
|
PortType
|
HUB-16P
|
|
|
||
|
9
|
Cabinet Size
|
960mm*320mm*135mm/double sides
|
|
|
||
|
10
|
Cabinet Weight
|
28KG
|
|
|
||
|
11
|
Cabinet resolution
|
480*80
|
|
|
||
|
12
|
Brightness
|
≥6000cd/m²
|
|
|
||
|
13
|
power consumption
|
Max:≤510W/PCS
|
|
|
||
|
14
|
Refresh Rate
|
1920HZ
|
|
|
||
|
15
|
View Angle
|
≥120°(Vertical),≥140°(Horizontal)
|
|
|
||
|
16
|
Gray level
|
16-65536 adjustment
|
|
|
||
|
17
|
Driving IC
|
ICN2055
|
|
|
||
|
18
|
Maximun Current
|
10A±0.05
|
|
|
||
|
19
|
Maximun power of unit board
|
≤50W
|
|
|
||
|
20
|
Mean free error time
|
≥5000 hours
|
|
|
||
|
21
|
Average power consumption
|
≤250W/PCS
|
|
|
||
|
22
|
Lifetime
|
100000 Hours
|
|
|
||
