Quick Details
-
Warranty:
-
12 years workmanship 30 years linear power output
-
Brand Name:
-
LESSO
-
Model Number:
-
182 Bifacial
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Application:
-
Solar Power System
-
Solar cell:
-
Mono 182*182mm
-
Product name:
-
182mm 144cells 525W-545W Half Cell
-
Glass:
-
2.0mm, highly transparent tempered glass with anti-reflective coating
-
Junction Box:
-
IP68 Rated
-
Cable:
-
4.0mm² 300 mm or customised length
-
Cell Type:
-
Mono-crystalline
-
Weight:
-
32.3kg
-
OEM Order:
-
Acceptable
-
Frame:
-
Anodized Aluminium Alloy
-
Certificate:
-
TUV CE CQC ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass
-
Panel Efficiency:
-
21.2%
-
Warranty:
-
12 years workmanship 30 years linear power output
-
Brand Name:
-
LESSO
-
Model Number:
-
182 Bifacial
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Application:
-
Solar Power System
-
Solar cell:
-
Mono 182*182mm
-
Product name:
-
182mm 144cells 525W-545W Half Cell
-
Glass:
-
2.0mm, highly transparent tempered glass with anti-reflective coating
-
Junction Box:
-
IP68 Rated
-
Cable:
-
4.0mm² 300 mm or customised length
-
Cell Type:
-
Mono-crystalline
-
Weight:
-
32.3kg
-
OEM Order:
-
Acceptable
-
Frame:
-
Anodized Aluminium Alloy
-
Certificate:
-
TUV CE CQC ISO
|
PARAMETERS TABLE
|
|
|
|
Product Name
|
182 MBB Bifacial Half-cell Mono Perc Module
|
|
|
Place of Origin
|
Guangdong, China
|
|
|
Maximum Efficiency
|
21.20%
|
|
|
Warranty
|
12 years product workmanship warranty, 30 years linear power output warranty
|
|
|
Front Glass
|
2.0mm, highly transparent tempered glass with anti-reflective coating
|
|
|
Power Range
|
525-545W
|
|
|
Brand Name
|
LESSO
|
|
|
Module Dimension
|
2278*1134*35mm
|
|
|
Panel Size
|
2.58㎡
|
|
|
Certificate
|
N/A
|
|
|
ODM/OEM
|
OEM/ODM
|
|
|
Weight
|
32.3kg
|
|
|
Frame
|
Anodized aluminium alloy
|
|
|
Working Temperature
|
- 40~+70℃
|
|
|
Cables
|
4mm² PV cable, 300mm or customized length
|
|
|
Maximum System Voltage
|
1500V DC
|
|
|
Nominal Maximum Fuse Current
|
25A
|
|
|
Trade Terms
|
EXW
|
LESSO factory (SHUNDE/ HESHEN)
|
|
|
Trade Terms
|
FOB
|
GUANGZHOU, SHENZHEN, etc.
|
|
|
|
CIF/CFR
|
To be decided.
|
|
|
Payment Terms
|
T/T
|
100% T/T before shipment, 30% T/T deposit + 70% T/T before shipment.
|
|
|
|
L/C
|
100% L/C at sight, 30% T/T deposit + 70%L/C at sight.
|
|
|
|
Other
|
To be decided.
|
|
|
Currency Acceptable
|
|
USD, EURO, RMB, etc.
|
|
