Quick Details
-
Data Storage Options:
-
Cloud
-
Product Name:
-
Door Lock
-
Material:
-
Zinc Alloy
-
Color:
-
Black
-
Door thickness:
-
Above 38mm
-
Unlock method:
-
Mechinical Key
-
Battery:
-
6V(4*1.5V AAA Batteries)
-
Unlock way:
-
Key + Key
-
Feature:
-
Durable High Safety
-
Function:
-
Multi-function
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YGS
-
Model Number:
-
9906
-
Data Storage Options:
-
Cloud
-
Product Name:
-
Door Lock
-
Material:
-
Zinc Alloy
-
Color:
-
Black
-
Door thickness:
-
Above 38mm
-
Unlock method:
-
Mechinical Key
-
Battery:
-
6V(4*1.5V AAA Batteries)
-
Unlock way:
-
Key + Key
-
Feature:
-
Durable High Safety
-
Function:
-
Multi-function
Specification
|
Product Name
|
9906
|
|
Application
|
Hotel
|
|
Material
|
Zinc Alloy
|
|
Unlock way
|
Card+Key
|
|
Function
|
Inside Doors
|
|
Power supply
|
4PCS AAA Alkaline Battery
|
|
Feature
|
Easy Installation
|
|
Warranty
|
3 Years
|
|
Lock body
|
stainless steel
|
|
Lock cylinder
|
C-Level
|
|
Surface color
|
Black/Gold
|
|
Working temperature
|
-25℃ ∼ 65 ℃
|
|
Working humidity
|
20% ∼ 95% RH
|
|
Storage temperature
|
-20 ℃ ∼ 85℃
|
|
Storage humidity
|
10% ∼ 98% RH
|
|
Indoor faceplate
|
H175*W66*D20 mm
|
|
Outdoor faceplate
|
H200*W66*D20 mm
|
|
Mortise life
|
400000 cycles
|
|
Battery
|
4 pcs AAA alkaline batteries
|
|
Battery life
|
150000 times
|
|
Access solution
|
RFID card/Mechanical key
|
|
Emergency unlocking
|
Mechanical key
|
|
Mortise
|
ANSI Standard
|
1,Suitable for aggressive environment
♦ The PCB was dealed with silicon ecapsulated treatment
♦ The PCB was assembled with imported brand components
♦ After a variety of surface treatment , the panel sealed glaze treatment at last
♦ Experienced a 72 hour salt spray test
♦ The PCB was dealed with silicon ecapsulated treatment
♦ The PCB was assembled with imported brand components
♦ After a variety of surface treatment , the panel sealed glaze treatment at last
♦ Experienced a 72 hour salt spray test
2,Convenient for hotel management
♦ 1000 audit trail , convenient for hotel management
♦ Using MF1 chip, which can achieve all-in-one-card solution function
♦ The door lock management system can be integrated into the hotel management system , such as fidelio,opera and so on
♦ A handheld device can set the lock and collect the data efficiently
♦ 1000 audit trail , convenient for hotel management
♦ Using MF1 chip, which can achieve all-in-one-card solution function
♦ The door lock management system can be integrated into the hotel management system , such as fidelio,opera and so on
♦ A handheld device can set the lock and collect the data efficiently
|
|
YGS Advantage
|
|
|
Function
|
Us
|
Peers
|
|
Lock design
|
Unique
|
Common
|
|
Housekeeping card
|
√
|
×
|
|
Free handle
|
√
|
√
|
|
Interface
|
Fidelio,Opera
|
Others
|
|
Audit trail
|
1000
|
800
|
|
Battery life
|
1500 times, about 3 years
|
About 2 years
|
|
Motor reset time
|
less than 0.25s
|
less than 1s
|
|
Power dissipation
|
Static current <20uA
Dynamic current<150mA
|
Static current<30uA
Dynamic current<200mA
|
|
Delivery time
|
10 to 25 days after payment
|
10 to 60 days after payment
|
Product Description
Master carton size: 56.5*49*28.5
3 pcs/ctn
