Quick Details
-
Dimension(L*W*H):
-
According to customization
-
Weight:
-
17500 KG
-
Product Name:
-
Large Capacity Steel Coffee Bean Silo for Sale OEM/ODM Accept
-
Certification:
-
ISO9001/ISO14001/OHSAS18001
-
Dimension:
-
According To The Capacity
-
Capacity:
-
100-10,000T
-
Bottom Type:
-
Flat/Hopper
-
Grain Silo Service Life:
-
25-30 Years
-
WeChat/WhatsApp:
-
+86 13598071775
Quick Details
-
Core Components:
-
Steel Plate
-
Place of Origin:
-
Henan, China, Henan, China
-
Brand Name:
-
HKB, HKB
-
Dimension(L*W*H):
-
According to customization
-
Weight:
-
17500 KG
-
Product Name:
-
Large Capacity Steel Coffee Bean Silo for Sale OEM/ODM Accept
-
Certification:
-
ISO9001/ISO14001/OHSAS18001
-
Dimension:
-
According To The Capacity
-
Capacity:
-
100-10,000T
-
Bottom Type:
-
Flat/Hopper
-
Grain Silo Service Life:
-
25-30 Years
-
WeChat/WhatsApp:
-
+86 13598071775
Large Capacity Steel Coffee Bean Silo for Sale OEM/ODM Accept
| Product Description |
As the name implies, grain warehouse is a warehouse for storing grain. The selection of grain silo should be conducive to food security storage, be advanced to a certain extent, be conducive to the realization of mechanization,and be suitable for the implementation of advanced grain storage technology.
Hopper bottom steel silos store materials out of the silos with good self-cleaning effect and no residue. The warehouse is suitable for seed, flour, aquaculture, chemical and other industries with moderate reserves and frequent silos. The hopper bottom steel silo support structure of the cone-bottom steel plate warehouse is strong and the cone-bottom strength is high.
| Technical Parameter |
| 500Ton Hopper Bottom Steel Silo Technical Parameter | |||||
| Project | Layer Number | V(m3) | C(t) | Dia(m) | H(m) |
| TCZK08212 | 12 | 838 | 628 | 8.250 | 21.11 |
| TCZK08213 | 13 | 898 | 673 | 8.250 | 22.23 |
| TCZK09109 | 9 | 826 | 619 | 9.167 | 18.36 |
| TCZK09110 | 10 | 900 | 675 | 9.167 | 19.48 |
| TCZK10008 | 8 | 931 | 698 | 10.084 | 18.01 |
The above data is for reference only. For more information, please contact us.
Professional team to answer your questions online
|
Deatails |
|
Silo Roof The roof beam is made of C-shaped steel, the upper part is connected with the tio ring of the silo, the lower part is connected with the pillar of the silo,and the beam is horizontally connected by angle steel to form the framework of the silo top. |
|
|
Silo Body The coaming of the silo is made of 275g/m2 galvanized steel plate. The coaming is gradually thicjened from top to bottom according to the stress of each layer. |
|
|
|
Access Ladder & Door HKB Brand high-strength galvanized ladders have roll-formed sides and stamped rungs to eliminate rung spin for easily climbing. The access doors gives the second ring to access to the interior of the silo. |
|
Accessory Equipment |
Henan Haokebang Machinery Equipment Co., Ltd. specializes in the production of 100-10,000 ton hopper bottom and flat bottom corrugated galvanized steel silos. According to various factors such as site, weather, and geology, we provide professional silo design, equipped with elevators, unloading pits, pre-cleaner, conveyors, sweeping auger and other accessories to meet the diverse needs of customers.
| Loading&Delivery |
|
Workshop |
Standing on our strong integral solution design power, HKB’s s rich manufacturing expertise guarantees the best workmanship of the whole silo system. The bolt steel plate production line is imported assuring bolt plates high precision and max sealing bolt connection. The introduction of advanced laser cutting machine, intelligent CNC robot and silo hoarding forming machine ensures that the steel plate is cut accurately and efficiently, the incisions are flat and beautiful, the silo has high strength, good seismic performance and long service life.
