Quick Details
-
Voltage:
-
380v/3phase/50hz
-
Disc Dia.:
-
Auto Spray Paint Booth
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SINO STAR
-
Model Number:
-
SS-9100
-
Warranty:
-
1 year
-
Product name:
-
Used paint mixing machine
-
Front Door(mm):
-
3000*2600(W*H)
-
Service Door (mm):
-
650*1800(W*H)
-
Air capacity for fresh air:
-
22000m3/h
-
Air Inlet fan system:
-
1*7.5kw turbo fan
-
Wall panel:
-
50mm EPS sandwich panel, steel sheet thickness: 0.426mm
-
Ceiling panel:
-
0.8mm galvanized steel sheet.
Quick Details
-
Power:
-
9KW, 9kw
-
External Size:
-
7006*5460*3420mm
-
Internal Size:
-
6900*4000*2650mm
-
Voltage:
-
380v/3phase/50hz
-
Disc Dia.:
-
Auto Spray Paint Booth
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SINO STAR
-
Model Number:
-
SS-9100
-
Warranty:
-
1 year
-
Product name:
-
Used paint mixing machine
-
Front Door(mm):
-
3000*2600(W*H)
-
Service Door (mm):
-
650*1800(W*H)
-
Air capacity for fresh air:
-
22000m3/h
-
Air Inlet fan system:
-
1*7.5kw turbo fan
-
Wall panel:
-
50mm EPS sandwich panel, steel sheet thickness: 0.426mm
-
Ceiling panel:
-
0.8mm galvanized steel sheet.
Sino Star Auto baking oven/ car painting room/ used paint mixing machine
Product Name: Used paint mixing machine
Product Model: SS-9100
CONTACT US: MOBILE:+86 15900433721 WHATSAPP:+86 15900433721
Product series:
Auto Spray Paint Booth/Advanced Car Spray Booth/Diesel Fuel Burner Spray Booth/China Inflatale Spray Booth/water based paint Spray Booth/SPRAY-PAINTED WORKSHOP/coating room/powder coating/ spray booth/spray tan booth/car spray paint baking booth/furniture spray booth paint booth/automotive spary booth/useful spary booth/small spary booth/cheap spary booth/industrial painting equipment
| 1. MODEL:SS-9100 | ||||||
| Outside Dimension (mm) | 7006*5460*3420(L*W*H) | Inside Dimension(mm) | 6900*4000*2650(L*W*H) | |||
| Front Door(mm) | 3000*2600(W*H) | Service Door (mm) | 650*1800(W*H) | |||
| Total Power | 9KW | Total Weight | 3.8t | |||
| Cabin System | Wall panel | 50mm EPS sandwich panel, steel sheet thickness: 0.426mm | ||||
| Ceiling panel | 0.8mm galvanized steel sheet. | |||||
| Basement | 300mm depth, two rows grids and three rows checkered plates. | |||||
| Ramps | Two pieces 2000*600mm ramps | |||||
| Glass | 5mmsafety tempered glass | |||||
| Windows | Square glass windows | |||||
| Air Make-up System | Air Inlet fan system | 1*7.5kw turbo fan | ||||
| Exhausted fan system | For option | |||||
| Air capacity for fresh air | 22000m3/h | |||||
| Exhausted ducting | 4meters straight ducting, one 90°elbow and one 45°elbow. | |||||
| Purification System | Pre-filter | G3 grade | ||||
| Ceiling filter | EU5 / F5 | |||||
| Floor filter | Fiber glass filter / G3 grade | |||||
| Exhausted fan filters | Fiber glass filter and active carbon | |||||
| Heating System | Heat exchanger | SUS304 material, argon arc welding. | ||||
| Heating burner: | RielloG20 diesel oil burner | |||||
| Heating productivity | 180000Kcal/h | |||||
| Spray to baking switch | Pneumatic damper | |||||
| Chimney ducting | 3 meters stainless ducting and one chimney elbow | |||||
| Max heating temperature | 80°C | |||||
| fuel consumption | 6-8L/vehicle | |||||
| Lighting System | Ceiling lights | 8 Units, each 4 * 18W LED lamps. Total 576 W | ||||
| Side lights | Side lights For option | |||||
| Illumination | 800LUX | |||||
| Controlling System | Switched control panel | Spraying & baking A33:G51switch,lighting switch, emergency stop, breakdown alarm, failure alarm | ||||
