- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SAIER
-
Model Number:
-
SEN-PPI35
-
Material:
-
PP plastic
-
Connection:
-
M10
-
Medium:
-
water or liquid no damage to the float ball
-
Working voltage:
-
below DC24V
-
Custom made:
-
Wire harness specification, dimension of float
-
Installation method:
-
Vertical entry 35mm
-
Switching power:
-
10W, normally open (NO)
-
Work Temperature:
-
0-60°C
-
Warning point, switching power:
-
Customized
-
Max Voltage/Electric current:
-
DC110V, less than 0.5A
Quick Details
-
Grade:
-
DIY, Industrial
-
Warranty:
-
1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SAIER
-
Model Number:
-
SEN-PPI35
-
Material:
-
PP plastic
-
Connection:
-
M10
-
Medium:
-
water or liquid no damage to the float ball
-
Working voltage:
-
below DC24V
-
Custom made:
-
Wire harness specification, dimension of float
-
Installation method:
-
Vertical entry 35mm
-
Switching power:
-
10W, normally open (NO)
-
Work Temperature:
-
0-60°C
-
Warning point, switching power:
-
Customized
-
Max Voltage/Electric current:
-
DC110V, less than 0.5A
Certifications
Product Description
SEN-BP21W
SEN-BP43W
|
Product Name
|
PP plastic vertical mount water tank float level switch control
|
|
|
|
|
||||
|
Material
|
PP plastic
|
|
|
|
|
||||
|
Connection Size
|
M10
|
|
|
|
|
||||
|
Contact Capacity
|
AC220v/1A; DC24V/0.5A
|
|
|
|
|
||||
|
Function
|
Float Switch, apply to level control and alarm of all kinds of industry such as electronic, electric power, chemical,
watertreatment, water supply and drainage. |
|
|
|
|
||||
|
Function
|
The working principle of PP vertical float level switch is direct and simple. Set one point or multipoint of magnetic switch in
sealed unmagnetic metal or industrial plastic tube. Fix the float with inner magnetic system to a certain place of magnetic switch in the pipe and let the float drift up and down; utilize the inner magnetic system in the float to trigger the open and close of magnetic switch to operate and control the liquid level. |
|
|
|
|
||||
Impeller Flowmeter
Application: Coffee machine & capsule coffee machine.
Material: Food grade
