Quick Details
-
Optical Resolution:
-
648*488
-
Scan Speed:
-
300 Scans/sec
-
Brand Name:
-
Symcode
-
Place of Origin:
-
Guangdong, China
-
Model:
-
MJ-2020
-
Size:
-
Wired:19.5(H)* 7.5(W)* 13.3(L)cm
-
Weight:
-
Wired:185 g
-
Working Current:
-
MJ-2020(Wired):360mA(RMS)
-
Standby Current:
-
MJ-2020(Wired):100 mA(RMS)
-
Color:
-
Black+Orange(Other color optional)RED-Green-orange
-
Interfaces:
-
USB, RS232,USB-COM(Other interfaces optional)
-
Illumination:
-
Red light 634nm LED
-
European Union Security Law:
-
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + AC 2011 + A2: 2013;
-
Certification:
-
FCC / RoHS / CE
Quick Details
-
Type:
-
Handheld
-
Scan Element Type:
-
CMOS
-
Max Paper Size:
-
A4s
-
Optical Resolution:
-
648*488
-
Scan Speed:
-
300 Scans/sec
-
Brand Name:
-
Symcode
-
Place of Origin:
-
Guangdong, China
-
Model:
-
MJ-2020
-
Size:
-
Wired:19.5(H)* 7.5(W)* 13.3(L)cm
-
Weight:
-
Wired:185 g
-
Working Current:
-
MJ-2020(Wired):360mA(RMS)
-
Standby Current:
-
MJ-2020(Wired):100 mA(RMS)
-
Color:
-
Black+Orange(Other color optional)RED-Green-orange
-
Interfaces:
-
USB, RS232,USB-COM(Other interfaces optional)
-
Illumination:
-
Red light 634nm LED
-
European Union Security Law:
-
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + AC 2011 + A2: 2013;
-
Certification:
-
FCC / RoHS / CE
1. Adopt advanced radio frequency wireless technology, singal penetrates walls, ceilings and floors more effectively. Delivers up to 1500m /1000m . allowing workers to scan faster and farther.heavy duty industrial grade barcode scanner is built to withstand harsh working environment and ensure superior durability. complete dust proof and to withstand impact from drops of up to 9.84ft to concrete floor.
2. Comes with cradle / 433 wireless Connection ,Superior battery power management delivers the largest number of scans per battery charge to support scan intensive applications.
3. The barcode reader has over 300 configuration options, allowing you to add prefix and suffix codes, or to delete
starting/ending characters. You can even add keyboard keys/combinations to the scanning operation.
4. Barcode scanner can easily scan 1D/2D bar codes on labels, paper, and mobile phone or computer screen.compatible work with Windows XP/7/8/10, Mac OS, Linux, etc system, and work well with multiple common software like Word, Excel.
5.For supermarkets, shopping malls, cosmetic stores, retail industry, postal industry, logistics, banks and medical
institutions.easy to use.
| Size | Wired:19.5(H)* 7.5(W)* 13.3(L)cm |
| Weight | Wired:185 g |
| Voltage | Min 4.5 VDC,Max 5.5 VDC |
| Working Current | MJ-2020(Wired):360mA(RMS) |
| Standby Current | MJ-2020(Wired):100 mA(RMS) |
| Color | Black+Orange(Other color optional)RED-Green-orange |
| Interfaces | USB, RS232,USB-COM(Other interfaces optional) |
| Indicators | LED,Buzzer Beep,Vibration(Optional) |
| Illumination | Red light 634nm LED |
| Focus | 655nm Square red light |
| Field of view | Level:31º ;Vertical:23º |
| Sensor | 800X800 Laser |
| Print Contrast | ≥15% |
| Scan Angle | Deflection:± 60°;Pitch:± 60° |
| Decode Ability | 1D:Code 39, Code 128, Code 93, Codabar/NW7,Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| Working Temperature | Wired:-22ºF to 122ºF/-30ºC to 50ºC |
| Standby Temperature | -40ºF to 158ºF/-40ºC to 70ºC |
| Humidity: | 5% to 95%(Non-condensing) |
| Drop Specification | Can withstand the impact of multiple drops from a height of 8.0 feet/2.4 meters to the concrete floor |
| Rolling Specifications | 5000 rolls from a height of 3.3 feet (1 meter) |
| Sealing Grade | IP65 and IP67; |
| Electrostatic Discharge(ESD) | Comply with EN61000-4-2, ±20 KV air discharge, ±10 KV direct discharge, ±10 KV indirect discharge |
| Anti-ambient light | 0 to 10,037 foot candles/0 to 108,000 Lux (direct sunlight) |
| Environmental Parameters | RoHS EN 50581 |
| Electrical Safety | European Union Security Law:EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + AC 2011 + A2: 2013; |
Scanner Can Read UPC, ISBN, EAN and almost all the bar code labels in the world
Adopt advanced radio frequency wireless technology, singal penetrates walls, ceilings and floors more effectively. Compared to 2.4GHz wireless scanner, the scanner has the advantage of strong signal and long transmission distance The transmission in barrier free environment can reach up to 1000 meter . The transmission distance in obstacles environment is less than 150 m
Can withstand repeated drops of 1.8M
1.Easy to Use : Plug and Play , Apply to whether being utilized in retail store, supermartket, library, warehouse, Inventory,
express shipping, ERP, POS, and more it can read almost of 1D/2D barcode like UPC / EAN (include complement code), Code128, Code39, Code 39 Full ASCII, Codabar, industrial/Interleaved 2 of 5, Code93, MSI, Code11, ISBN/ISSN, etc compatible with Windows XP/ 7 / 8 10, Mac OS, Linux.iPad.Android.Mac.phone
2.Settings: support instant upload and storage mode two types use modes, also support turn on or off the sound and vibration, hide/add custom prefix/suffix digits, delete character, add keyboard keys (TAB, CR&LF, etc.) to the scanning operation and so on Key the trigger to begin scanning or switch to automatic mode for quick scanning without pressing any buttons
3.BT Wireless Connection +charging base Only press scan button 8-10 seconds can easily turn on BT and directly connect with your phone, tablets and PC. The charging base was used as receiver
5.Package :
*1 x Barcode Scanner+BT+Charging base
*1 x 433 Dongle
*1 x USB Cable
*1 x User Manual
PS :Doesn't work square terminal
