2 WIFI Antennas provide better WIFI signal;
2 Kiosks on 1 Stand to save room.
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
2 Years, 24 months
-
Application:
-
Restaurant
-
Installation:
-
Wall Mountable
-
Optional parts:
-
NFC/MSR/RFID
-
Color:
-
White
-
Display size:
-
32 inch
-
Dispaly touch:
-
True-flat PCAP touch with multi-touch support
-
OS Support:
-
Win 10 IoT
-
Printer:
-
3" thermal printer w/auto cutter, 170 mm/sec (max.)
-
Operation System:
-
Windows
-
CPU:
-
J6412/i3/i5
-
Hard Disk Capacity:
-
128gb/256gb
Quick Details
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Self-service Kiosk Machine
-
Warranty:
-
2 Years, 24 months
-
Application:
-
Restaurant
-
Installation:
-
Wall Mountable
-
Optional parts:
-
NFC/MSR/RFID
-
Color:
-
White
-
Display size:
-
32 inch
-
Dispaly touch:
-
True-flat PCAP touch with multi-touch support
-
OS Support:
-
Win 10 IoT
-
Printer:
-
3" thermal printer w/auto cutter, 170 mm/sec (max.)
-
Operation System:
-
Windows
-
CPU:
-
J6412/i3/i5
-
Hard Disk Capacity:
-
128gb/256gb
Product Specifications
|
HModel Number
|
|
H30
|
|
|
|
||||
|
Processor
|
|
Celeron J1900
|
i3-6100U
|
i5-6200U
|
Celeron J6412
|
||||
|
System Memory
|
|
DDR3
|
DDR4 4G, SO-DIMM*1, (Max.16GB)
|
|
|
||||
|
Storage device
|
|
MSATA（Optional 64G/128G/256G）
|
|
|
|
||||
|
Power Supply
|
|
12V/8A x 1（Host）+ 24V/2A x 1（Printer）
|
|
|
|
||||
|
OS Support
|
|
Win 7/Win 10 IoT
|
|
|
Win 10 IoT
|
||||
|
Display
|
Size
|
32 Inch
|
|
|
|
||||
|
|
Resolution
|
1920*1080
|
|
|
|
||||
|
|
Brightness
|
290~320 cd/m²
|
|
|
|
||||
|
|
touch
|
True-flat PCAP touch with multi-touch
|
|
|
|
||||
|
Interface
|
Power Port
|
DC-IN x 1，DC-OUT x 1
|
|
|
|
||||
|
|
VGA Port
|
VGA x 1
|
|
|
|
||||
|
|
HDMI Port
|
HDMI x 1
|
|
|
|
||||
|
|
USB Port
|
USB3.0 x 2 + USB2.0 x 6
|
|
|
|
||||
|
|
LAN Port
|
LAN x 2（10/100/1000 Mbt）
|
|
|
|
||||
|
|
Audio
|
intel Speaker x 2，Audio x 1( combo)
|
|
|
|
||||
|
|
Serial Port
|
RJ50*2，DB9*1
|
|
|
|
||||
|
Components
|
Printer
|
3" thermal printer w/auto cutter, 170 mm/sec (max.)
|
|
|
|
||||
|
|
Camera
|
2MP wide angle camera (Face recognition camera for option)
|
|
|
|
||||
|
|
Proximity Sensor
|
80CM Infrared induction module
|
|
|
|
||||
|
|
horn
|
Speaker*2(L+R)
|
|
|
|
||||
|
|
Status indicator
|
for printer status
|
|
|
|
||||
|
Optional
|
WIFI
|
PCI-E WiFi/BT module
|
|
|
|
||||
|
|
Sanner
|
capature scanner
|
|
|
|
||||
|
|
MSR
|
MSR
|
|
|
|
||||
|
|
EMV device
|
Custom bracket support for various EMV payment devices
|
|
|
|
||||
|
|
NFC/RFID Reader
|
1、Support ISO/IEC 14443-A&B (MIFARE), JIS x 6319-4 (Felica), NFC protocols - tag read/write (ISO/IEC-18092)
2、ISO/IEC 15693---non-support |
|
|
|
||||
|
|
Projection lamp
|
External projection lamp
|
|
|
|
||||
|
Environmental
|
Operating
|
0°C - 50°C; 20%RH - 90%RH
|
|
|
|
||||
|
|
Storage
|
-20°C - 70°C; 10%RH - 90%RH
|
|
|
|
||||
Product Description
Detailed Functions/ Parts of Elanda S30 series Kiosk.
Blue/ Red indicator light easy to know status;
Custom LED LOGO
Elanda Latest Self-service Kiosk offers an optional custom LED Logo to make retailers/ sellers' brand more impressive on users.
Multiple Mount Options
S30 self-ordering kiosk offers counter-top, floor-stand, wall-mount, double kiosk on 1 floor stand, etc. Meeting all business needs for the deployment needs.
2 EMV Payment Device Brackets
S30 Kiosk aims at convenience for the sellers
There are 2 options of EMV payment device brackets to choose from.
5MP Camera
5 million pixels camera as S30 kiosk standard configuration
Face recognition camera available for extra need for some business types.
32" HD LCD & TP
For great user/ customers visual experience, S30 Kiosk series provide an High resolution 32" TFT LCD screen and an high quality touch panel to deal with self-service orders while peak time.
Scanner
2D barcode/ QR scanner for fast and easy operation when users/ customers are using smartphones.
NFC/ RFID Reader
For card users, NFC/ RFID Reader is a option for swift making payment.
S30 reader support
1, ISO/IEC 14443-A&B (MIFARE), JIS x 6319-4 (Felica), NFC protocols - tag read/write (ISO/IEC-18092)
2, ISO/IEC 15693---non-support
2, ISO/IEC 15693---non-support
MSR
S30 3-track MSR is an option peripheral for traditional mechanical card reading
Thermal Printer
S30 Series thermal printer is with auto-cutter and prints at
170 mm/sec (max), which is an enhanced user experience
Elanda S30 Series are designed for easy deployment/ installation/ maintenance, time/ cost saving.
Slim body, Elegant look, Fashion Style with Aesthetic, suitable for most situations like
Airport
Hospital
Bookstore
Supermarket
Clothing shop
Shopping mall
, etc.
Packaging
Packing
Finished
Contact us now:
Click Here
Related Products
Certifications
Shenzhen Elanda Tech. Certificates
Shenzhen Elanda has ISO 9001, National Hi-Tech, Patents, FCC, CE, ROHS, EMC, etc. If need any, feel free to contact us.
Our Company
Shenzhen Elanda Office Elanda Show Room QC Department
Shenzhen Elanda Tech Co., Ltd. is located in BaoAn district, Shenzhen, 4.6 Km away from Shenzhen airport..
Company area:
6000 square meters,
factory area: 5000
square meters.
Elanda comply with CE, FCC, ROHS, ISO 9001, etc.
Shenzhen Elanda Production Lines and Warehouse
Elanda could always guarantee perfect products and timely delivery to our customers,
welcome OEM and ODM projects.
Shenzhen Elanda R&D Team / Aging / QA Testing
Elanda focuses on research & development, production, QC for industrial level POS system, kiosk and thermal printer.
Elanda Exhibitions
Shenzhen Elanda Exhibitions From 2015-2023
Contact us now:
Click Here
FAQ
Q
1
: Are you a manufacturer?
A: Yes, we are a professional POS machine manufacturer located in Shenzhen. And we provide OEM&ODM services too.
A: Yes, we are a professional POS machine manufacturer located in Shenzhen. And we provide OEM&ODM services too.
Q2: What is the lead-time for my order?
A: 3-5 days for sample order and 15-20 days for bulk order.
Q3: What is your warranty policy?
A: 1-3 years warranty for most of the products (based on the model), three years of free maintenance.
Q4: What payment methods your company accept?
A: Alibaba Trade Assurance Payment, T/T, L/C, Paypal, Western Union etc.
Q5: How about your product packaging?
A: Packed in pearl cotton with carton box or wooden case.
Q6: Can I order a sample to check the quality?
A: Yes of course! You can order a sample to check the quality.
