Quick Details
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Saining
-
Model Number:
-
Multiwall-Four
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Certificate:
-
ISO 9001
-
Technology:
-
Co-Extrusion
-
Material:
-
Polycarbonate resin
-
Thickness:
-
10mm
-
Color:
-
Clear, red, orange, Green, Blue, Bronze, Opal, etc
-
Size:
-
Cut to size
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
graphic design
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Saining
-
Model Number:
-
Multiwall-Four
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Certificate:
-
ISO 9001
-
Technology:
-
Co-Extrusion
-
Material:
-
Polycarbonate resin
-
Thickness:
-
10mm
-
Color:
-
Clear, red, orange, Green, Blue, Bronze, Opal, etc
-
Size:
-
Cut to size
| Polycarbonate four-wall sheet Product Standard & Technical Parameters | ||||
| Thickness(mm) | Weight(kg/m2) | Mini-bending radius(mm) | Transparency(%) | K value(W/M2.k) |
| 8 | 1.7 | 2400 | 71 | 2.56 |
| 10 | 2 | 3000 | 71 | 2.39 |
| 12 | 2.2 | 3600 | 70 | 2.3 |
| 14 | 2.4 | 4200 | 69 | 2.1 |
| 16 | 2.7 | 4800 | 68 | 2 |
| 18 | 3 | 5400 | 66 | 1.88 |
| 20 | 3.3 | 6000 | 63 | 1.69 |
| Technical Parameters | ||||||
| Impact strength | Transparency | Specific grevity | Coefficient of thermal expansion | Service temperature | Heat conductivity | |
| 2.1j/m-2.3j/m | 40%-80% | 1.2g/cm³ | 0.065mm/m°C | -40°C—120°C | 3.0-3.9w/m²°C | |
| Tensile strength | Flexural strength | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break | |
| ≥60N/mm | 100N/mm² | 2400Mpa | 10mm two laminates reduced 10db | ≥65Mpa | >100% | |
| packaging | Both sides with PE film, the end with paper tape, logo on the pe film. Other package are available based on customers' requirement. | |||||
| delivery | 7-10 days after receipt of deposit. | |||||
| capacity for 20 GP | 2.1m*5.8m*8mm | 300 sheet | ||||
| 2.1m*5.8m*10mm | 240 sheet | |||||
| 2.1m*5.8m*12mm | 200 sheet | |||||
| 2.1m*5.8m*14mm | 171 sheet | |||||
| 2.1m*5.8m*16mm | 150 sheet | |||||
| 2.1m*5.8m*18mm | 133 sheet | |||||
| 2.1m*5.8m*20mm | 120 sheet | |||||
| capacity for 40GP | 2.1m*5.8m*8mm | 600 sheet | 2.1m*11.8m*8mm | 300 sheet | ||
| 2.1m*5.8m*10mm | 480 sheet | 2.1m*11.8m*10mm | 240 sheet | |||
| 2.1m*5.8m*12mm | 400 sheet | 2.1m*11.8m*12mm | 200 sheet | |||
| 2.1m*5.8m*14mm | 342 sheet | 2.1m*11.8m*14mm | 171 sheet | |||
| 2.1m*5.8m*16mm | 300 sheet | 2.1m*11.8m*16mm | 150 sheet | |||
| 2.1m*5.8m*18mm | 266 sheet | 2.1m*11.8m*18mm | 133 sheet | |||
| 2.1m*5.8m*20mm | 240 sheet | 2.1m*11.8m*20mm | 120 sheet | |||
| capacity for 40HQ | 2.1m*5.8m*8mm | 674 sheet | 2.1m*11.8m*8mm | 337 sheet | ||
| 2.1m*5.8m*10mm | 540 sheet | 2.1m*11.8m*10mm | 270 sheet | |||
| 2.1m*5.8m*12mm | 450 sheet | 2.1m*11.8m*12mm | 225 sheet | |||
| 2.1m*5.8m*14mm | 384 sheet | 2.1m*11.8m*14mm | 192 sheet | |||
| 2.1m*5.8m*16mm | 336 sheet | 2.1m*11.8m*16mm | 168 sheet | |||
| 2.1m*5.8m*18mm | 300 sheet | 2.1m*11.8m*18mm | 150 sheet | |||
| 2.1m*5.8m*20mm | 270 sheet | 2.1m*11.8m*20mm | 135 sheet | |||
|
Brief introduction
|
||||||
|
A. Product Range
|
||||||
| 1).Twin-walls polycarbonate sheet thickness: 4,6,8,10,12 Width: 2100mm. | ||||||
| 2).Triple-walls polycarbonate sheet thickness: 8,10,12,14,16. Width: 2100mm. | ||||||
| 3).Four-walls polycarbonate sheet thickness: 8,10,12,14,16,18,20mm. Width: 2100mm. | ||||||
| 4).Honeycomb polycarbonate sheet thickness: 6,8,10,12,14mm. Width: 2100mm. | ||||||
| 5).X-structure polycarbonate sheet thickness: 14,16,18,20,25,30mm. | ||||||
| 6).Solid polycarbonate sheet [Compact] thickness:0.9-8.0mm. | ||||||
| Width: 1220,1560,1820,2100mm.Usually 1220*2440mm, 2050*3000mm | ||||||
| 7).Corrugated polycarbonate sheet: 0.8-2.5mm. Width is different. | ||||||
|
B.Length: No limit(Recommend 5800, 6000, 11800,12000mm to suit 20'container &40'container). |
||||||
|
C.Color: clear/transparent, lake blue, green, blue, opal, white, brown/bronze, silvery gray, red, yellow, etc. |
||||||
| Polycarbonate twin-wall sheet>> | Polycarbonate X-structure sheet>> | Polycarbonate embossed sheet>> | Polycarbonate solid corrugated sheet>> |
| Polycarbonate triple wall sheet>> | Polycarbonate U panel>> |
Polycarbonate diffusion sheet>>
|
Polycarbonate hollow corrugated sheet>> |
| Polycarbonate four-wall sheet >> | PC crystal sheet >> |
Polycarbonate Anti-scratch sheet
>>
|
Others( FRP, PMMA, PS,etc)>> |
| Polycarbonate honeycomb shee>> | Polycarbonate solid sheet >> | PC profile and accessories >> | U profile-polycarbonate clear>> |
| Packaging & Shipment |
Delivery time
Generally 15 working days after the order confirmed
Packaging
1) Custom package request is appreciate.
2) Standard package: Both Sides Covered With PE Film
