Quick Details
-
Panel Size:
-
640x1920mm
-
Media Available:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
V2.5
-
LED type:
-
SMD2020
-
Module size:
-
320*160mm
-
Cabinet size:
-
640*1920mm
-
Brightness:
-
1200cd/sqm
-
Refresh rate:
-
3840Hz
-
grey scale:
-
16bit
-
Display resolution:
-
196,608pixels
-
Material:
-
Aluminum
-
Warranty:
-
2 Years
-
Certificate:
-
CE ROHS FCC CCC ISO9001
Quick Details
-
Application:
-
Indoor, Outdoor, advertising/shopping guide
-
Brand Name:
-
CKGLED
-
Color:
-
full color
-
Panel Size:
-
640x1920mm
-
Media Available:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
V2.5
-
LED type:
-
SMD2020
-
Module size:
-
320*160mm
-
Cabinet size:
-
640*1920mm
-
Brightness:
-
1200cd/sqm
-
Refresh rate:
-
3840Hz
-
grey scale:
-
16bit
-
Display resolution:
-
196,608pixels
-
Material:
-
Aluminum
-
Warranty:
-
2 Years
-
Certificate:
-
CE ROHS FCC CCC ISO9001
Detailed Images
Feature
. Move at any time, can be combined and displayed.
. Plug and play, ultra-thin and lightweight,very convenient.
. Multimedia playback, USB, LAN, Wifi, supports multiple playback modes such as pictures and videos.
. One-key split screen, multiple display modes.
. The heat dissipation hole design has good heat dissipation effect.
. Plug and play, ultra-thin and lightweight,very convenient.
. Multimedia playback, USB, LAN, Wifi, supports multiple playback modes such as pictures and videos.
. One-key split screen, multiple display modes.
. The heat dissipation hole design has good heat dissipation effect.
Product Paramenters
|
NO.
|
DIsplay Parameters
|
Specifications
|
|
1
|
Diplay Model
|
V2.5
|
|
2
|
Pixel Pitch (mm)
|
2.5
|
|
3
|
Physical Density (dot/m2)
|
160000
|
|
4
|
LED Configuration
|
1R1G1B
|
|
5
|
LED Type
|
SMD2020
|
|
6
|
Module Size (mm x mm)
|
320*160
|
|
7
|
Module Resolution (PX x PX)
|
128X64
|
|
8
|
Drive Mode
|
1/32 Constant Current Drive
|
|
9
|
Viewing Angle (Deg)
|
H:140 / V: 140
|
|
10
|
Brightness (cd/m2)
|
1200
|
|
11
|
Grey Scale
|
16 bits
|
|
12
|
Refresh Rate (Hz)
|
3840
|
|
13
|
Cabinet Resolution (PX x PX)
|
256X768
|
|
14
|
Power Consumption (W/sqm)
|
MAX: 600 / AVE: 300
|
|
15
|
Cabinet Size (mm x mm)
|
640*1920
|
|
16
|
Cabinet Weight (Kg)
|
<39
|
|
17
|
Cabinet Material
|
aluminum
|
|
18
|
Input Voltage (V)
|
AC 110V~220V+/-10%
|
|
19
|
Refresh Frame Frequency (Hz)
|
60
|
|
20
|
Protection Level
|
IP43
|
|
21
|
Working Temperature (ºC)
|
-30°- +60°
|
|
22
|
Operation humidity (RH)
|
10%-95%
|
|
23
|
Certificates
|
CCC, CE, RoHS
|
Certifications
Product packaging
Wooden case pacakage
Company Introduction
Our Corporate
：
Shenzhen Chuangkaiguang Co., LTD (known as CKGLED), a professional LED display factory who specializes in R&D / DESIGN /PRODUCTION /SALES, was established in 2012 with a registered capital of more than $ 12 Million. CKGLED product ranks are indoor/outdoor rental led displays, Ultra small pixel pitch led displays, indoor/outdoor fixed installation led displays, sports /stadium led displays, traffic led displays etc.
The company has developed a long-term development strategy plan, adhere to the "Thanksgiving, integrity, innovation, focus" business management philosophy, to create the world's largest LED photoelectric display products integrated manufacturing service provider for the goal, we work together for common developmen.
The company has developed a long-term development strategy plan, adhere to the "Thanksgiving, integrity, innovation, focus" business management philosophy, to create the world's largest LED photoelectric display products integrated manufacturing service provider for the goal, we work together for common developmen.
Our service
Pre-Sales Service
Provide details about the production procedure
Assign engineers for installation and testing
Sales Service
Customized solution designs
Product rendering and steel structure drawing
CKGLED's successful project examples and visits to our production and R&D base
After-Sales Service
Two-year quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material): free repair service during the quality warranty period and reasonable charge
for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user's notification, we ensure 24-hour after-sales technical support.
Spare parts: necessary spare parts are provided together with products to customers.
Free technical training: integrative and normative technology training is available for free to customers by our technical
personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
Site instruction service of installation is available.
Free on-site service for hardware related issues.
Please call our technical support for more information: 0086 - 13632795492.
Provide details about the production procedure
Assign engineers for installation and testing
Sales Service
Customized solution designs
Product rendering and steel structure drawing
CKGLED's successful project examples and visits to our production and R&D base
After-Sales Service
Two-year quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material): free repair service during the quality warranty period and reasonable charge
for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user's notification, we ensure 24-hour after-sales technical support.
Spare parts: necessary spare parts are provided together with products to customers.
Free technical training: integrative and normative technology training is available for free to customers by our technical
personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
Site instruction service of installation is available.
Free on-site service for hardware related issues.
Please call our technical support for more information: 0086 - 13632795492.
FAQ
Q1: Could we print our own logo on led display products?
A: Of course. Please let us know all the details soon before production.
Q2: Do you offer guarantee for the led display products?
A: Yes, we offer 2 year warranty for our products in copper wire led and 3 years warranty for our gold wire product.
Q3: Whether to provide technical training (installation training and use training)?
A: Yes, we offer full service, Including pre-sale, sale, after-sales service, you can reply on us
Q4: Do you have any MOQ limit for led display order?
A: No MOQ, 1pc order for sample checking is available.
