- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Saier
-
Model Number:
-
SEN-HZ43WA
-
operating voltage range:
-
DC4.5-18V,could be customized 24V
-
Electrical strength:
-
AC500V,50HZ
-
Material:
-
Nylon
-
Flow Range:
-
2~60L/Min;2~45L/min
-
insulated resistor:
-
>100MΩ
-
water temperature:
-
less than 60 ℃
-
specifictation:
-
60*38*38mm
-
Output level:
-
Rated voltage DC5V,high level ≥4.5V,low level ≤0.5V
-
Pulse duty cycle:
-
50%
Quick Details
-
Type:
-
Variable Area Water Flowmeters
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Saier
-
Model Number:
-
SEN-HZ43WA
-
operating voltage range:
-
DC4.5-18V,could be customized 24V
-
Electrical strength:
-
AC500V,50HZ
-
Material:
-
Nylon
-
Flow Range:
-
2~60L/Min;2~45L/min
-
insulated resistor:
-
>100MΩ
-
water temperature:
-
less than 60 ℃
-
specifictation:
-
60*38*38mm
-
Output level:
-
Rated voltage DC5V,high level ≥4.5V,low level ≤0.5V
-
Pulse duty cycle:
-
50%
DN20 G3/4
/
water flow sensor n
ylon PA 66 material, apply to gas water heater, circulating water system,boosting heating, solar energy pump etc.
Certifications
Product Description
|
Product Name
|
Miniature nylon flowmeter water flow sensor, turbine flow sensor
|
|
|
|
|
||||
|
Material
|
nylon material
|
|
|
|
|
||||
|
Connection Size
|
OD 2-G3/4
|
|
|
|
|
||||
|
Flow Range
|
2-60L/Min;2-45L/Min
|
|
|
|
|
||||
|
Contact Capacity
|
DC 5-24V, can be customized DC 3V
|
|
|
|
|
||||
|
Function
|
Measure water flow, It is installed in various coffee machines, water dispensers, and water inlets of electrolyzers to detect the influent flow.
|
|
|
|
|
||||
Details Images
Impeller Flowmeter
Application:
gas water heater, circulating water system,boosting heating, solar energy pump
Material: nylon
