- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Henan, China
-
Dimension(Long * Breadth * High):
-
690*1778*800
-
Machine Weight:
-
800 kg
-
Bucket capacity:
-
0.2 cubic meter
-
Marketing Type:
-
New Product 2024
-
Max pin height (H2):
-
1803 mm
-
Max discharge height (H1):
-
1386 mm
-
The highest unload distance(E):
-
471mm
-
Max angle of unloading:
-
32
-
Total height(H):
-
1309mm
-
wheelbase(L1):
-
690 mm
-
The height from the ground(H1):
-
123mm
-
No bucket height(L3):
-
1778 mm
-
Total width (B2):
-
800 mm
-
Total length (L)(with bucket ):
-
2210 mm
Quick Details
-
Engine Brand:
-
CAMC
-
Power:
-
Other, 75 KW, 60 KW, 44.7 KW, 37 KW, 15.7 kw, 17.2 kw, 55 kw, 70 KW, 92 KW
-
Brand Name:
-
DH
-
Place of Origin:
-
Henan, China
-
Dimension(Long * Breadth * High):
-
690*1778*800
-
Machine Weight:
-
800 kg
-
Bucket capacity:
-
0.2 cubic meter
-
Marketing Type:
-
New Product 2024
-
Max pin height (H2):
-
1803 mm
-
Max discharge height (H1):
-
1386 mm
-
The highest unload distance(E):
-
471mm
-
Max angle of unloading:
-
32
-
Total height(H):
-
1309mm
-
wheelbase(L1):
-
690 mm
-
The height from the ground(H1):
-
123mm
-
No bucket height(L3):
-
1778 mm
-
Total width (B2):
-
800 mm
-
Total length (L)(with bucket ):
-
2210 mm
Product Description
Specification
|
Item
|
Metric
|
|
Max working height (H3)
|
2065mm
|
|
Max pin height (H2)
|
1803 mm
|
|
Max discharge height (H1)
|
1386 mm
|
|
The highest unload distance(E)
|
471mm
|
|
Max angle of unloading(α3)
|
32°
|
|
Retracting angle (α2)
|
33°
|
|
Angle of departure (α1)
|
18°
|
|
Total height(H)
|
1309mm
|
|
The height from the ground(H1)
|
123mm
|
|
wheelbase(L1)
|
690 mm
|
|
No bucket height(L3)
|
1778 mm
|
|
Total width (B2)
|
800 mm
|
|
Bucket width(B1)
|
820 mm
|
|
Total length (L)(with bucket )
|
2210 mm
|
|
Turning radius (R)
|
1236mm
|
