Quick Details
-
Model Number:
-
GC9015
-
Input voltage and current:
-
220VAC/3.75A
-
output voltage and current:
-
40~90V/15A
-
Maximum Output Power:
-
750W
-
Place of Origin:
-
Guangdong, China
-
style:
-
charge model
Quick Details
-
Type:
-
Power Supply Adapter, Universal Adapter, CAR CHARGER, Fast Charger, Motorcycle Ebike Power Exchange Cabinet
-
Port:
-
DC, AC
-
Brand Name:
-
Depower
-
Model Number:
-
GC9015
-
Input voltage and current:
-
220VAC/3.75A
-
output voltage and current:
-
40~90V/15A
-
Maximum Output Power:
-
750W
-
Place of Origin:
-
Guangdong, China
-
style:
-
charge model
Products Description
|
Variable Output Voltage(48V-90V) 1300W Battery Charger Model
|
|
|
|
|
||||
|
Model
|
|
|
GC9015
|
|
||||
|
Input
|
Voltage range
|
|
90～264 VAC
|
|
||||
|
|
Frequency range
|
|
45～65Hz
|
|
||||
|
|
Power Factor(Typ.)
|
|
≥0.98（Tested when the power is above half power）
|
|
||||
|
|
Input current(Typ.)
|
|
3.75A/220VAC
|
|
||||
|
|
Inrush current(Typ.)
|
|
50A/220VAC
|
|
||||
|
|
Max. Efficiency(Typ.)
|
|
93%
|
|
||||
|
|
Leakage current
|
|
<0.5mA/220VAC
|
|
||||
|
Output
|
Battery type
|
|
Lithium Battery
|
|
||||
|
|
Charging phase
|
|
constant current + constant voltage
|
|
||||
|
|
Output voltage range
|
|
40V~90V
|
|
||||
|
|
Max. output power
|
|
750W
|
|
||||
|
|
Max. output current
|
|
15A
|
|
||||
|
|
Max. current ripple
|
|
500mAp-p
|
|
||||
|
|
Start time
|
|
≤3S
|
|
||||
|
|
Over voltage protection
|
|
Vset+2V
|
|
||||
|
|
Short circuit
|
|
Yes
|
|
||||
|
|
Over temperature
|
|
Yes
|
|
||||
|
Communication
|
Communicaton mode
|
|
RS485
|
|
||||
|
|
Communication description
|
|
Customer’s
|
|
||||
|
Environment
|
Working Temp
|
|
–20～60℃
|
|
||||
|
|
Working humidity
|
|
10%～90%RH non-condensing
|
|
||||
|
|
Storage temp., humidity
|
|
–40～80℃ ， 10%～90%RH non-condensing
|
|
||||
|
|
Vibration resistant
|
|
10～500HZ，2G 10minutes/cycle,X,Y,Z axis each 60 minutes
|
|
||||
|
SAFETY & EMC
|
Safety standards
|
|
GB/T 4706
|
|
||||
|
|
Withstand voltage
|
|
I/P-O/P：3KVAC I/P-FG：2KVAC O/P-FG：0.5KVAC
|
|
||||
|
|
Isolation resistance
|
|
I/P-O/P，I/P-FG，O/P-FG：100Mohms/500VDC/25℃/70%RH
|
|
||||
|
|
EMC emission
|
|
GB/T 9254 Class A；
|
|
||||
|
|
EMC immunity
|
|
GB/T17618;
|
|
||||
|
|
MTBF
|
|
>70K
|
|
||||
|
|
Weight
|
|
0.75kg/199*98*50mm (L*W*H)
|
|
||||
|
|
Dimensions
|
|
12pcs/10.1kg/423*255*270mm (L*W*H)
|
|
||||
Charging Efficiency Curve
Maximum Output Current Graph
