Quick Details
-
Application:
-
Machinery
-
Working medium:
-
Compressed Air
-
Material:
-
Stainless Steel Material
-
Work pressure:
-
0.1-1.0MPa
-
Color:
-
Sliver
Quick Details
-
Weight (KG):
-
0.52
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
JXPC
-
Application:
-
Machinery
-
Working medium:
-
Compressed Air
-
Material:
-
Stainless Steel Material
-
Work pressure:
-
0.1-1.0MPa
-
Color:
-
Sliver
Product Description
| Cylinder Diameter | 8 | 10 | 12 | 16 | 20 | 25 |
| Working Medium | Air | |||||
| Motion Pattern | Double Action or Single Action | |||||
| Ensured Pressure Resistance | 15.3kgf/cm2(1.5Mpa) | |||||
| Max. Pressure | 10.2kgf/cm2(1.0Mpa) | |||||
| Min. Pressure | 0.5kgf/cm2(0.05Mpa) 1kgf/cm2(0.1Mpa) | |||||
| Environment and fluid temp | -20·+80℃ Internal Magnetic intall by Tach strap:Type Max.60℃ | |||||
| Buffering | Rubber Bufer (Standard) Air Buffer(Option) | |||||
| Piston veocity | 50~750mm/s | |||||
| (kgf/cm)Kinetic energy to Lerance(kgf/cm) | 0.2 | 0.3 | 0.4 | 0.9 | 2.7 | 4 |
| Port Size | M5*0.8 |
G1/8''
|
||||
