Quick Details
-
Brand Name:
-
BRANDO
-
Orifice Size:
-
15mm, 20mm, 25mm, 35mm, 50mm
-
Body Material:
-
Brass
-
Seal Material:
-
PTFE
-
Working Pressure:
-
0.5 to 25 bar
-
Operation:
-
Piston Pilot Operated
-
Function:
-
2 Way Normally Closed, 2 Way Normally Closed
-
Voltage:
-
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Quick Details
-
Port Size:
-
3/8'', 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
PS
-
Brand Name:
-
BRANDO
-
Orifice Size:
-
15mm, 20mm, 25mm, 35mm, 50mm
-
Body Material:
-
Brass
-
Seal Material:
-
PTFE
-
Working Pressure:
-
0.5 to 25 bar
-
Operation:
-
Piston Pilot Operated
-
Function:
-
2 Way Normally Closed, 2 Way Normally Closed
-
Voltage:
-
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
How To Order
Technical Data
|
Model No
|
Port Size
|
Orifice Size
|
Cv
|
Working Pressure
|
Body
|
Seal
|
Voltage
|
|
PSX15B03
|
3/8''
|
15mm
|
4.6
|
0.5 to 25 bar
|
Brass
SS304
|
PTFE
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
PSX15B04
|
1/2''
|
15mm
|
4.6
|
0.5 to 25 bar
|
|
|
|
|
PSX20B06
|
3/4''
|
20mm
|
8.5
|
0.5 to 25 bar
|
|
|
|
|
PSX25B25
|
1''
|
25mm
|
12
|
0.5 to 25 bar
|
|
|
|
|
PSX35B32
|
1-1/4''
|
35mm
|
26
|
0.5 to 25 bar
|
|
|
|
|
PSX35B40
|
1-1/2''
|
35mm
|
26
|
0.5 to 25 bar
|
|
|
|
|
PSX50B50
|
2''
|
50mm
|
48
|
0.5 to 25 bar
|
|
|
|
|
Model No
|
Port Size
|
Orifice Size
|
Cv
|
Working Pressure
|
Body
|
Seal
|
Voltage
|
|
PSX15K03
|
3/8''
|
15mm
|
4.6
|
0.5 to 16 bar
|
Brass
SS304
|
PTFE
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
PSX15K04
|
1/2''
|
15mm
|
4.6
|
0.5 to 25 bar
|
|
|
|
|
PSX20K06
|
3/4''
|
20mm
|
8.5
|
0.5 to 25 bar
|
|
|
|
|
PSX25K25
|
1''
|
25mm
|
12
|
0.5 to 25 bar
|
|
|
|
|
PSX35K32
|
1-1/4''
|
35mm
|
26
|
0.5 to 25 bar
|
|
|
|
|
PSX35K40
|
1-1/2''
|
35mm
|
26
|
0.5 to 25 bar
|
|
|
|
|
PSX50K50
|
2''
|
50mm
|
48
|
0.5 to 25 bar
|
|
|
|
Main Dimension
|
Model No
(Normally Closed)
|
Port
|
A
|
B
|
C
|
|
PSB15B03
|
3/8''
|
68
|
49
|
122
|
|
PSB15B04
|
1/2''
|
68
|
49
|
122
|
|
PSB20B06
|
3/4''
|
76
|
57
|
133
|
|
PSB25B25
|
1
|
96
|
70
|
144
|
|
PSB35B35
|
1-1/4''
|
120
|
90
|
168
|
|
PSB35B40
|
1-1/2''
|
120
|
90
|
168
|
|
PSB50B50
|
2''
|
150
|
112
|
190
|
|
Model No
(Normally Open)
|
Port
|
A
|
B
|
C
|
|
PSB15K03
|
3/8''
|
68
|
49
|
122
|
|
PSB15K04
|
1/2''
|
68
|
49
|
122
|
|
PSB20K06
|
3/4''
|
76
|
57
|
133
|
|
PSB25K25
|
1
|
96
|
70
|
144
|
|
PSB35K35
|
1-1/4''
|
120
|
90
|
168
|
|
PSB35K40
|
1-1/2''
|
120
|
90
|
168
|
|
PSB50K50
|
2''
|
150
|
112
|
190
|
