Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Xuanhai
-
Model Number:
-
RDZB-720
-
Voltage:
-
1.1-1.5kw
-
Dimension(L*W*H):
-
4750x2100x1450mm
-
Weight:
-
2000 KG
-
Usage:
-
Rolling garbage bag,trash bag,dog pop bag,
-
Bag type:
-
coreless garbage bag
Quick Details
-
Machine Type:
-
Bag Forming Machine
-
Bag Type:
-
GARBAGE BAG
-
Material:
-
Plastic
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Xuanhai
-
Model Number:
-
RDZB-720
-
Voltage:
-
1.1-1.5kw
-
Dimension(L*W*H):
-
4750x2100x1450mm
-
Weight:
-
2000 KG
-
Usage:
-
Rolling garbage bag,trash bag,dog pop bag,
-
Bag type:
-
coreless garbage bag
Products Description
The HDPE\LDPE bags by this machine are applying to supermarket shopping and garbage bags
Advantage:
Advantage:
1. This bag making machine is applied to making perforation coreless rolling garbage bags or rubbish bags. And without paper-core star sealing bags or flat sealing bags.
specially designed for point-off 8 fold continuous-rolled L-type HDPE\LDPE bag making machine.
are applying to supermarket shopping ,vegetable bag,garbage bag. Also suitable for different kind of biodegradable bag such as PLA, PBAT,cornstarch, Caco3,etc.
2. Double bag film rolls with double functions unwinding structure.
3. Folding unit *2sets.
4. The machine adopts computer control system. setting length system to make the sealing size with less error.
2. Double bag film rolls with double functions unwinding structure.
3. Folding unit *2sets.
4. The machine adopts computer control system. setting length system to make the sealing size with less error.
adjust the bag length,print bags a problem the machine automatically shut down and alarm.
Color mark tracking photocell
track the precise location of the pattern of the printed bags.
5. Automatic rewinder. This machine is equipped with automatic bag rolls rewinding and changing
6. With functions such as double bag film roll unwinding, folding system, photocell automatic tracking, strong heat-sealing
device, microcomputer length setting, Taiwan Delta inverters, automatic counting, automatic alarm when reaching the set figure, digital temperature controller, automatic bag rolls rewinding and changing.
7. It is an ideal fully automatic equipment to produce roll garbage bags, or for the bag plant to improve efficiency and reduce the labor demand device of choice.
5. Automatic rewinder. This machine is equipped with automatic bag rolls rewinding and changing
6. With functions such as double bag film roll unwinding, folding system, photocell automatic tracking, strong heat-sealing
device, microcomputer length setting, Taiwan Delta inverters, automatic counting, automatic alarm when reaching the set figure, digital temperature controller, automatic bag rolls rewinding and changing.
7. It is an ideal fully automatic equipment to produce roll garbage bags, or for the bag plant to improve efficiency and reduce the labor demand device of choice.
|
Model
|
RDZB-700 two lines rolling
|
|
|
VOLTAGE
|
220V 3PHASE
|
|
|
Suitable materials
|
HDPE,LDPE
|
|
|
Producing length
|
400-1200mm
|
|
|
Producing width(two lines)
|
200-500mm (BEFORE FOLDING)
|
|
|
Final products width
|
100-250mm
|
|
|
Producing width(one line)
|
300-600mm (without FOLDING)
|
|
|
Final products width(one line)
|
300-600mm
|
|
|
Producing speed
|
70m/min
|
|
|
Total power
|
9.0kw
|
|
|
Film of thickness
|
0.008-0.025mm
|
|
|
Max. sealing layer
|
8
|
|
|
Weight
|
2000kg
|
|
|
Overall size
|
4750x2100x1450mm
|
|
|
Main parts brand
|
|
|
|
item
|
brand
|
details
|
remark
|
|
Main machine inverter
|
Delta inverter
|
1.5KW
|
1pc
|
|
Feeder motor
|
Delta inverter
|
0.75KW
|
2pcs
|
|
winding motor(cutting blade rubber roll)
|
Delta inverter
|
0.75kw
|
2pcs
|
|
Rewinding motor
|
Delta inverter
|
0.75KW
|
4pcs
|
|
Reverse turning motor
|
Delta inverter
|
0.75KW
|
1pc
|
|
Length fixed motor
|
FUJI servo motor
|
2KW
|
1pc
|
|
Controller
|
Hangzhou risheng
|
Touch screen
|
1pc
|
|
Sealing blade and Cutting knife together
|
|
|
1set
|
product details
Touch screen control
Can set bag length,speed,batch
Double unwinder rollers
Color mark tracking
Make colored bags
Two rolls bag auto come out
Folding device to fold your bag
Two copper sealing knives to seal and perforation cut the bag
IMPROVE MACHINE ALL THE WAY
ONLY OUR MACHINE HAS BLOWER FOR ELECTRIC BOX TO COOLING THE TEMPERATURE
NICE PAINTING FOR THE MACHINE STRUCTURES
HIGH QUALILTY PARTS PROCESS AND INSTALLMENT THAN OTHER SUPPLIERS
