- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
DP-CR2000
-
Output Frequency:
-
50/60 Hz
-
Size:
-
39.7*25.3*15.5CM
-
Weight:
-
4.85kg
-
Output waveform:
-
Pure Sine Waveform
-
Inverter type:
-
High Frequency Solar Off-grid Inverter
-
Protection Function:
-
Over-current Protection.overload Protection
-
Phase:
-
Single Phase Power Inverter
-
Application:
-
Solar Power System Home
-
Overload capacity:
-
100%~120%(60s)
-
Advantage:
-
Low Power Consumption
-
Warranty:
-
1 Year/12 Months
-
Certificate:
-
PSE,FCC,CE,UKCA,ROHS,IS9001
Quick Details
-
Output Current:
-
10-61v
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
DOD
-
Model Number:
-
DP-CR2000
-
Output Frequency:
-
50/60 Hz
-
Size:
-
39.7*25.3*15.5CM
-
Weight:
-
4.85kg
-
Output waveform:
-
Pure Sine Waveform
-
Inverter type:
-
High Frequency Solar Off-grid Inverter
-
Protection Function:
-
Over-current Protection.overload Protection
-
Phase:
-
Single Phase Power Inverter
-
Application:
-
Solar Power System Home
-
Overload capacity:
-
100%~120%(60s)
-
Advantage:
-
Low Power Consumption
-
Warranty:
-
1 Year/12 Months
-
Certificate:
-
PSE,FCC,CE,UKCA,ROHS,IS9001
VR Showroom
Unpacking Video
Product Details
Optional wattage:
|
Parameters
|
|
|
|
|
|
|
||||||
|
Output
|
Model
|
|
DP-CR2000-121
|
DP-CR2000-122
|
DP-CR2000-241
|
DP-CR2000-242
|
||||||
|
|
Rated Power
|
|
2000W
|
|
|
|
||||||
|
|
Surge Power
|
|
4000W (few seconds)
|
|
|
|
||||||
|
|
Output Voltage
|
|
110VAC±5%
|
230VAC±10%
|
110VAC±5%
|
230VAC±10%
|
||||||
|
|
Frequency
|
|
60Hz±1Hz
|
|
|
|
||||||
|
|
Output Waveform
|
|
Pure Sine Wave
|
|
|
|
||||||
|
|
Total Harmonic Distortion
|
|
THD<3% (Linear Load)
|
|
|
|
||||||
|
Input
|
Rated Input Voltage
|
|
12VDC
|
|
24VDC
|
|
||||||
|
|
Input Voltage Range
|
|
9.5-16V
|
|
19-32V
|
|
||||||
|
|
Input Current At No Load
|
|
0.7±0.1A
|
|
0.8±0.1A
|
|
||||||
|
|
Low Input Voltage Alarm
|
|
10±0.5V
|
|
20±0.5V
|
|
||||||
|
|
Low Input Voltage Shut Down
|
|
9.5±0.5V
|
|
19±0.5V
|
|
||||||
|
|
Low Input Voltage Recovery
|
|
12.5±0.5V
|
|
25±0.5V
|
|
||||||
|
|
High Input Voltage Shut Down
|
|
16±0.5V
|
|
32±0.5V
|
|
||||||
|
|
High Input Voltage Recovery
|
|
14V±0.5V
|
|
28V±0.5V
|
|
||||||
|
Connection
|
Output
|
|
Different socket type optional
|
|
|
|
||||||
|
|
Type-C
|
|
20W
|
|
|
|
||||||
|
|
Remote
|
|
Remote controller optional
|
|
|
|
||||||
|
|
2 USB Voltage
|
|
5.±0.2V
|
|
|
|
||||||
|
|
USB Output current
|
|
3.4A
|
|
|
|
||||||
|
General
|
Soft Start
|
|
YES
|
|
|
|
||||||
|
|
Output Efficiency
|
|
> 90% (At full load)
|
|
|
|
||||||
|
|
Cooling Way
|
|
Temperature controlled fan. Fan ON at 45°C ;
Fan OFF at 42°C (sensed at internal hot spot) |
|
|
|
||||||
|
|
Protection
|
|
Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit, Reverse Polarity
|
|
|
|
||||||
|
|
Working Temperature
|
|
0℃ - +45℃
|
|
|
|
||||||
|
|
Net Dimension
|
|
26*12.5*7cm (L×W×H)
|
|
|
|
||||||
|
|
Inner Box Dimension
|
|
39.7*25.3*15.5CM (L×W×H)
|
|
|
|
||||||
|
|
N.W./Unit
|
|
3.9kg
|
|
|
|
||||||
|
|
G.W./Ctn
|
|
4.85KGs
|
|
|
|
||||||
|
|
Packing
|
|
Colour box
|
|
|
|
||||||
|
|
Warranty
|
|
2 Years
|
|
|
|
||||||
Auto Protection
Certifications
Our Factory
FAQ
Q1: Why you should choose us?
OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
---More than 15 years solar products producing experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---More than 15 years solar products producing experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---solar panel : 10 years warranty ;
Hybrid inverter , charge controller , battery : 1-3 years warranty
--- we offer 1% sapre parts for free , will repair the PCB or provide new one
Q3: What kind of certification you have? OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
---ISO9001,ISO14001, CE, ROHS, TUV ,UL and so on
---All series product pass different testing according to different countries’ requirements.
Q4: Delivery time:
Hybrid inverter , charge controller , battery : 1-3 years warranty
--- we offer 1% sapre parts for free , will repair the PCB or provide new one
Q3: What kind of certification you have? OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
---ISO9001,ISO14001, CE, ROHS, TUV ,UL and so on
---All series product pass different testing according to different countries’ requirements.
Q4: Delivery time:
--Standard products could be delivered within 15 days after payment ;
Q5. Can I have a sample order? OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
---Yes, we welcome sample order to test and check quality.
OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
Q6. Do you have any MOQ?
Q5. Can I have a sample order? OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
---Yes, we welcome sample order to test and check quality.
OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
Q6. Do you have any MOQ?
---Yes, we have MOQ , it depends on different models.
Most products 1~10pcs sample order is available. Lowest MOQ : 1 pc
Q7. Do you support OEM , ODM ?
Most products 1~10pcs sample order is available. Lowest MOQ : 1 pc
Q7. Do you support OEM , ODM ?
---Yes. OEM & ODM is available , just tell us your idea , we can design it for you .
OEM& ODM MOQ depends on different models .
OEM& ODM MOQ depends on different models .
OffGrid inverters converters 2kva 2000w power inverter 120V 230V Pure Sine Wave 12V 24V 2Kw solar power inverter ups charger
