Quick Details
-
Model Number:
-
CTF-010
-
Brand Name:
-
Tianfei
-
Product name:
-
Electric ball valve
-
Connection:
-
BSP, NPT and G thread
-
Body material:
-
UPVC,CPVC,cast steel,cast iron,stainless steel
-
Certificate:
-
ISO, RoHS, CE
-
Working pressure:
-
1.6Mpa
-
Voltage:
-
AC220v
-
Manual Override:
-
yes
-
Working Temperature:
-
-10°C-40°C/14°F-108°F
-
Wiring control mode:
-
CR11 CR12
Quick Details
-
Port Size:
-
Ball valve(DN15-65),butterfly valve(DN50-DN125), Ball valve(DN15-65),butterfly valve(DN50-DN125)
-
Warranty:
-
1 year
-
Place of Origin:
-
Tianjin, China
-
Model Number:
-
CTF-010
-
Brand Name:
-
Tianfei
-
Product name:
-
Electric ball valve
-
Connection:
-
BSP, NPT and G thread
-
Body material:
-
UPVC,CPVC,cast steel,cast iron,stainless steel
-
Certificate:
-
ISO, RoHS, CE
-
Working pressure:
-
1.6Mpa
-
Voltage:
-
AC220v
-
Manual Override:
-
yes
-
Working Temperature:
-
-10°C-40°C/14°F-108°F
-
Wiring control mode:
-
CR11 CR12
AC220v 3 inch 3 way electric motorized upvc valve with Electric and manual override design
Product Description
| Product model | CTF-010 |
| Output torque | 100NM |
| Rated voltage | AC220V |
| Power | 25W |
| Working current | 1000mA |
| Open/close time | 18-25s |
| Position Indicator | Yes |
|
Manual override
Manual Operation |
yes |
| Feedback Signal | |
| Gear Material | |
| Working pressure | Max1.6Mpa |
| Environment temperature | 0-50℃ |
| Product life time | |
| Medium temperature | 0-90℃ |
| IP Grade | IP65 |
| Valve Body Material |
UPVC
CPVC cast steel cast iron stainless steel |
| Valve size |
Ball valve(DN15-65)
Butterfly valve(DN50-DN125) |
| Control mode | CR11 CR12 |
| Thread Standard |
G
BSPP NPT |
| Connection Method |
Thread Screw
Adhesive |
| Sealing |
Silicon Rubber
NBR EPDM |
| Seat | PTFE |
