Quick Details
-
Application:
-
position sensor
-
Usage:
-
Position Sensor
-
Theory:
-
Inductance Sensor
-
Output:
-
Analog SENSOR
Quick Details
-
Model Number:
-
I5CF I5CN I5PF I5PN
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
Biduk
-
Application:
-
position sensor
-
Usage:
-
Position Sensor
-
Theory:
-
Inductance Sensor
-
Output:
-
Analog SENSOR
%
Product Description
| Technical data | |
| Installing | Flush/Non-flush |
| Sensing distance |
0.1-30 mm |
| LED display | NO |
| Operation voltage | 18-30VDC |
| Ripple | <10% |
| No load current | <35mA |
| Output voltage/current load resistor | 0-10VDC/≥2KΩ |
| Linearity | <5% |
| Output sugnial with led | PNP-ANALOG |
| Frequency | 1.5KHZ |
| Protection category | IP67 |
| Operating temperature | -25℃----+70℃ |
| Temperature drift | <5%sr |
| Short circuit protection/reverse polarity protection | Yes |
| Overload trip point | 220mA |
| Material active face | PBT |
| Connecting way | 2 M cable/M8 Connector/ M12 Connector |
