Quick Details
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Dimensions (L x W x H) (mm):
-
Optional
-
Place of Origin:
-
Shandong, China
-
Name:
-
bitumen transportation tank
-
Tyre:
-
11.00R20-18PR 12R22.5-18PR
-
Certification:
-
ISO9001
-
Axle brand:
-
FUWA
-
Color:
-
any painting and logo depend on you
-
King Pin:
-
90#/50#
-
Volume:
-
customised
-
Function:
-
Transport bitumen
-
keywords:
-
bitumen storage tank container truck trailer
Quick Details
-
Condition:
-
New
-
Brand Name:
-
AOTONG
-
Gross Vehicle Weight:
-
10ton
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Dimensions (L x W x H) (mm):
-
Optional
-
Place of Origin:
-
Shandong, China
-
Name:
-
bitumen transportation tank
-
Tyre:
-
11.00R20-18PR 12R22.5-18PR
-
Certification:
-
ISO9001
-
Axle brand:
-
FUWA
-
Color:
-
any painting and logo depend on you
-
King Pin:
-
90#/50#
-
Volume:
-
customised
-
Function:
-
Transport bitumen
-
keywords:
-
bitumen storage tank container truck trailer
Heated Asphalt bitumen storage transportation tank truck trailer for sale ( Volume optional)
bitumen transportation tank , bitumen storage tank container truck trailer , bitumen asphalt tank trailer , bitumen trailer
Bitumen Asphalt Transportation Tank Truck Semi Trailer specification for reference
|
30CBM BITUMEN ASPHALT TANK TRUCK SEMI TRAILER |
|||||||||||||||||
|
DIMENSIONS |
|||||||||||||||||
|
Tare weight |
9000kg |
Volume |
30m3 |
||||||||||||||
|
Overall length |
10000mm |
Overall width |
2500mm |
Overall height |
3800mm |
||||||||||||
|
Tank body |
Q235/5mm steel |
Shape:cylinder end plate :6mm Manhole cover: Aluminum alloy API manhole cover, 500mm ,2 sets |
|||||||||||||||
|
Outside sheet |
1.2mm steel sheet |
Insulating materials&chickness:rock wool/fiber glass/polyurethane; 50mm-100mm |
|||||||||||||||
|
Axle |
Number |
2 |
Brand |
Fuwa |
Capacity |
13T |
|||||||||||
|
Suspension |
Mechanical suspension |
|
|||||||||||||||
|
Leaf spring |
10 spring leaf s |
||||||||||||||||
|
Heating device |
Optional |
||||||||||||||||
|
Tire |
12R22.5 9 pcs |
||||||||||||||||
|
Discharge valve |
4 ''disc valve |
||||||||||||||||
|
Dischage pipe |
4 "seamless steel tube |
||||||||||||||||
|
Kingpin |
2’’ bolt-in king pin and 3.5 bolt-in king pin |
|
|||||||||||||||
|
Landing gear |
Fuwa brand two-speed,manual operating ,heavy duty landing gear 28t |
||||||||||||||||
|
Bottom valve |
1-2 sets of Aluminum API Pneumatic Bottom Valve |
||||||||||||||||
|
Main beam |
Standard |
||||||||||||||||
|
Braking system |
RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
||||||||||||||||
|
Paiting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
||||||||||||||||
|
Accessories |
One standard tool box.fire extinguisher 2 pcs |
|
|||||||||||||||
|
Main beams |
Opting for high tensile steel Q345B welded by automatic submerged-arc processes |
||||||||||||||||
|
Remark |
Wax spray |
||||||||||||||||
|
Heater |
Equipped |
|
|
|
|||||||||||||
|
|
|||||||||||||||||
