- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
W-82C&W-15CP
-
Dimension:
-
544*245*375mm
-
Storage:
-
Other
-
SNR:
-
NA
-
Output Power:
-
250W(RMS)500W(PEAK)
-
Format:
-
NA
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB
-
Color:
-
Black
-
Power handling:
-
250W(RMS)500W(PEAK)
-
Nominal impedance:
-
8 ohm
-
Sensitivity:
-
96dB(1W1M)
-
MaxS.P.L:
-
116dB(PEAK/1M)
-
Output section:
-
2-channel
-
Surface finish:
-
Black paint
-
Input connectors:
-
2*NL4MP speakon
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-82C&W-15CP
-
Dimension:
-
544*245*375mm
-
Storage:
-
Other
-
SNR:
-
NA
-
Output Power:
-
250W(RMS)500W(PEAK)
-
Format:
-
NA
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB
-
Color:
-
Black
-
Power handling:
-
250W(RMS)500W(PEAK)
-
Nominal impedance:
-
8 ohm
-
Sensitivity:
-
96dB(1W1M)
-
MaxS.P.L:
-
116dB(PEAK/1M)
-
Output section:
-
2-channel
-
Surface finish:
-
Black paint
-
Input connectors:
-
2*NL4MP speakon
Product Description
|
Model
|
W-82C & W-15C/W-15CP(Active)
|
|
Type
|
Line array system
line arry sub-bass system(W-15C/W-15CP)
|
|
Frequency Response
|
70Hz-20KHz±3dB
40Hz-500Hz±3dB(W-15C/W-15CP)
|
|
Power handling
|
250W(RMS)500W(PEAK)
500W(RMS)1000W(PEAK)(W-15C/W15CP)
|
|
Sensitivity
|
96dB(1W1M)
106dB(1W1M)(W-15C/W15CP)
|
|
Max SPL
|
116dB(PEAK/1M)
130dB(1W1M)(W-15C/W15CP)
|
|
Drivers
|
LF 1×8"(210mm)woofer 50mm(2in)coil
LF 15"(380mm)woofer 100mm(4in)coil(W-15C/W-15CP) |
|
Nominal impedance
|
8 ohm
|
|
Coverage
|
110°H×9°V
|
|
Finish
|
Textured paint
|
|
Connectors
|
2×NL4MP speakon
|
|
Enclosure
|
Birch Plywood
|
|
Dimensions
|
544×245×375mm(W×H×D)
515×450×611mm(W×H×D)(W-15C/W-15CP)
|
|
Packing Dimensions
|
615×315×445mm/0.09cbm
585×520×680mm/0.22cbm(W-15C/W-15CP)
|
|
Net weight
|
12.5kg(W-82C)/34kg(W-15C)/40kg(W-15CP)
|
|
Gross weight
|
14.5kg(W-82C)/37kg(W-15C)/43kg(W-15CP)
|
