Quick Details
-
Place of Origin:
-
Guangdong,China
-
Brand Name:
-
Yuanfeng
-
Model Number:
-
YA1
-
Electrical Life:
-
10000times
-
Color:
-
Custom made
-
Certificate:
-
CQC CE ROHS ISO9001
-
Contact Resistance:
-
≤50mΩ
-
Switch Shell Materials:
-
Nylon Plastics
-
Ambient Temperature:
-
≤100℃
-
Dielectric Strength:
-
2500VAC/50-60Hz/5mA/1s
-
Certification:
-
CQC,CE,CB,TUV
Quick Details
-
Protection Level:
-
IP40
-
Max. Current:
-
16A
-
Max. Voltage:
-
125V/250V
-
Place of Origin:
-
Guangdong,China
-
Brand Name:
-
Yuanfeng
-
Model Number:
-
YA1
-
Electrical Life:
-
10000times
-
Color:
-
Custom made
-
Certificate:
-
CQC CE ROHS ISO9001
-
Contact Resistance:
-
≤50mΩ
-
Switch Shell Materials:
-
Nylon Plastics
-
Ambient Temperature:
-
≤100℃
-
Dielectric Strength:
-
2500VAC/50-60Hz/5mA/1s
-
Certification:
-
CQC,CE,CB,TUV
Products Description
|
Rating
|
16A, 125/250V AC
|
|
Switch Shell Materials
|
Nylon Plastics
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance（at 500VDC
|
≥100MΩ
|
|
Dielectric Strength
|
2500VAC/50-60Hz/5mA/1s
|
|
Ambient Temperature
|
≤100℃
|
|
Switch Mechanical Life
|
≥10000 press actuation
|
|
Switch Electric Life
|
20000 actuation at 2A current /5000 actuation at 16A current
|
|
Electric clearance
|
≥3
|
|
Creepage distance
|
≥5
|
