classification
|
unit
|
Specification parameters
|
|
|
|
Wavelength range
|
nm
|
850±40/1300±40
|
1260～1650
|
|
|
Test wavelength
|
nm
|
850/1300
|
1310/1550
|
|
|
Insert loss
|
dB
|
Typ:0.6 Max:1.0
|
|
|
|
Echo loss
|
dB
|
MM≥30 SM≥ 50
|
|
|
|
Channel crosstalk
|
dB
|
MM≥35 SM≥ 55
|
|
|
|
Polarization-related losses
|
dB
|
≤0.05
|
|
|
|
Wavelength correlation loss
|
dB
|
≤0.25
|
|
|
|
Temperature-related losses
|
dB
|
≤0.25
|
|
|
|
Repeatability
|
dB
|
≤±0.02
|
|
|
|
Working voltage
|
V
|
3.0 or 5.0
|
|
|
|
Service life
|
frequency
|
≥107
|
|
|
|
Switching time
|
ms
|
≤8
|
|
|
|
Transmission optical power
|
mW
|
≤500
|
|
|
|
Working temperature
|
oC
|
-20～+70
|
|
|
|
Storage temperature
|
oC
|
-40～+85
|
|
|
|
Weight
|
g
|
16
|
|
|
|
Dimensions
|
mm
|
1×1、1×2、2×4、2×2B、2×2F
D2×2B、4×4F |
(L)27.0x(W)12.0x(H)8.2
|
|
|
|
|
1x4
|
(L)23.0x(W)27.0x(H)8.2
|
|
|
|
|
1x8
|
(L)35.0x(W)35.0x(H)9.0
|
|
|
A
|
B
|
C
|
D
|
E
|
F
|
G
|
|
Fiber Type
|
Test Wavelength
|
Operating Voltage
|
Switch Type
|
Tube Type
|
Fiber Length
|
Connector
|
|
SM: SM, 9/125
M5:MM, 50/125 M6:MM, 62.5/125 X: Others |
85: 850±40nm
O: O band(1260~1360nm) C: C band(1530~1565nm) L: L band(1565~1625nm) U: U band(1625~1675nm) FS: 1260~1650nm |
3: 3V
5: 5V |
L: Latching
N: Non-latching |
25:250um(Bare fiber)
90:900um X: Others |
05: 0.5m±5m
10: 1.0m±5m 12: 1.2m±5m 15: 1.5m±5m X: Others |
OO: None
LP: LC/PC LU: LC/UPC LA: LC/APC FP: FC/PC FU: FC/UPC FA: FC/APC SP: SC/PC SU: SC/UPC SA: SC/APC STP: ST/PC STA: ST/APC X: Others |
