Quick Details
-
Product name:
-
horizontal laminar air flow cabinet/clean bench/workbench supplier
-
Item::
-
clean workbench
-
working persons::
-
for 1 persion working
-
wind speed::
-
0.25-0.45 m/s
-
illumination::
-
≥300 lx
-
noise::
-
≤62 dB
-
voltage::
-
110V / 220V
-
workshop::
-
410*670*440mm
-
net weight::
-
40kg
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Yaoke
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support
-
Product name:
-
horizontal laminar air flow cabinet/clean bench/workbench supplier
-
Item::
-
clean workbench
-
working persons::
-
for 1 persion working
-
wind speed::
-
0.25-0.45 m/s
-
illumination::
-
≥300 lx
-
noise::
-
≤62 dB
-
voltage::
-
110V / 220V
-
workshop::
-
410*670*440mm
-
net weight::
-
40kg
ISO-5 two-persons portable vertical laminar flow hood/clean bench
Information and Application
ISO-5 two-persons portable vertical laminar flow hood/clean bench is a purification equipment featuring high throughput capacity that provides highly purgative local working environment.
ISO-5 two-persons portable vertical laminar flow hood/clean bench is widely applied in teaching, pharmacy, sanitation, electronics, bioengineering, scientific experiments, etc. and an apparatus commonly used in microbiology, tissue culture, molecular biology experiments.
Features:
ISO-5 two-persons portable vertical laminar flow hood/clean bench
1,Vertical air flow, open table design.
2,We make the working zone spacious and bright by adopting mini-pleat hepa filters, minimizing the size of plenum chamber, adopting imported stainless steel table and acrylic side board.
3,Countertops can be detached from the main construction which reduces the influence from main construction's vibrancy.
4,We adopt advanced variable air volume air supply system and tact switch to improve and facilitate air volume adjustable range.
ALTERNATIVE OPTIONAL:
ISO-5 two-persons portable vertical laminar flow hood/clean bench
a.up-and-down spring type door
b.Ultraviolet sterilamp
c.Non-standard clean benches are available
d.double sides bench( can be made up clean assembly)
e.Ion stick controlled by ESD
f.ULPA filter
g.uv lamp
|
Type
|
YK-1000
|
YK-1300
|
YK-1600
|
||
|
Overall Dimension(mm)
|
W1000*L740*H1460
|
W1300*L740*H1460
|
W1600*L740*H1460
|
||
|
Shower Dimension (mm)
|
W980*L480*H610
|
W1285*L480*H610
|
W1590*L480*H610
|
||
|
Air Volume(m/h)
|
900
|
1200
|
1500
|
||
|
Air Speed(m/h)
|
0.45m/s ±20%
|
|
|
||
|
Environment Clean Grade
|
Class 100(ISO14644-1 International standard)
|
|
|
||
|
HEPA Efficiency
|
99.99at0.3um
|
|
|
||
|
HEPA Size
|
915*610*69
|
1220*610*69
|
915*610*69 610*610*69
|
||
|
Surface Material
|
304 Satin Stainless Steel
|
|
|
||
|
Noise
|
less58dB
|
less58dB
|
less60dB
|
||
|
Testing Point
|
In front of the surface 20cm,above the ground 1.2m
|
|
|
||
|
Voltage
|
220VAC 50Hz
|
|
|
||
|
People Available
|
1
|
1-2
|
2-3
|
||
Besides ISO-5 two-persons portable vertical laminar flow hood/clean bench，
Temperature humidity chamber, Temperature humidity control cabinet, Walk-in stability chamber, Precision hot air oven, Salt Spray Tester, Dustproof hot oven, Rain/Spray Test Chamber, Dust Test chamber, Automatic glue dispensing machine, Thermal Shock Tester, Temperature humidity & Vibration Combined Testing Chamber, Burn-in testing equipment, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester, etc.
Warranty & Service
1. Warranty period: one year from the purchase day.
2. During the warranty period, use the product in accordance with the printed instructions but encountered a problem and then we will provide free maintenance. If the product didn't work and after the confirmation and then we'll send a new one for free.
3. Engineers available to service machinery overseas
4. Beyond the warranty period, the product problems also can be solved by our company, but charge component cost and maintenance cost properly.
5. We welcome your call our hotline or email us for consulting, maintenance and other services.
6. OEM and ODM available
7. "Good quality, Reasonable price, Punctual delivery, Sincere service" is our company's commitment to you
ISO-5 two-persons portable vertical laminar flow hood/clean bench
1. How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
2. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
3. Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.
4. Do you have customers of our country before?
Now our testing machines have been sold to more than 26 countries, like USA, Canada, Russia,UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam, Brazil...and so on.
5. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
6. What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging- balance payment - packing - delivery - customer receiving - after service.
7. How to install and use the product?
The product is shipped with an operating instructions and video of English version.
ISO-5 two-persons portable vertical laminar flow hood/clean bench
