Quick Details
-
Product name:
-
XVR
-
Video input:
-
8 Channels
-
Video Compression:
-
265/264/MJPEG
-
Video Output:
-
1ch VGA+1ch HDMI
-
Playback:
-
8ch Playback
-
HDD:
-
Max 6TB/HDD
-
Warranty:
-
2 Years
-
Feature:
-
support 5MP
-
Keyword:
-
Hybrid DVR
-
Language:
-
Multi-language
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FOSVISION
-
Model Number:
-
FS-6308Plus
-
Product name:
-
XVR
-
Video input:
-
8 Channels
-
Video Compression:
-
265/264/MJPEG
-
Video Output:
-
1ch VGA+1ch HDMI
-
Playback:
-
8ch Playback
-
HDD:
-
Max 6TB/HDD
-
Warranty:
-
2 Years
-
Feature:
-
support 5MP
-
Keyword:
-
Hybrid DVR
-
Language:
-
Multi-language
Specification
|
System
|
Main processor
|
FS-6308PLUS
|
|
|
Operation system
|
Embedded LINUX operation system
|
|
|
System resources
|
Multichannel real time record
|
|
|
|
Multichannel real time playback
|
|
|
|
multichannel multi-user on network operation
|
|
Interface
|
Operation system
|
graphic menu operation interface, support mouse to operate
|
|
|
Image display
|
1/4/6/9/16 screen
|
|
|
Language
|
English, traditional Chinese, simplified Chinese, Japanese, Russian, German, Italian, Turkish, polish, Spanish, Korean,
Indonesian, Thai, Arabic, Persian, Vietnamese, French, Portuguese, Greek, Czech |
|
Video
|
Image coding
|
264/265
|
|
|
Surveillance quality
|
VGA(Max 1080P)；HDMI(Max 1080P), CVBS optional
|
|
|
Preview
|
8*5MP-N@20fps/8*4MP-N@25fps/8*1080P@25fps
|
|
|
Code capacity
|
8*5 MP-N@12fps/8*4MP-N@17fps/8*1080P@15fps
|
|
|
Decode capacity
|
8*5 MP-N@12fps/8*4MP-N@17fps/8*1080P@15fps
|
|
|
Various mode input
|
Coaxial: 8*5MP-N
|
|
|
|
Mixed: 4MP-N(coaxial)+1080P (IP) Arbitrary combination for coaxial and IP hybrid mode
|
|
|
|
IP: 8*5MP, 16*5MP for all IP mode
|
|
|
Recognize method
|
Automatic Identification、All AHD、All TVI、All CVI、Customized
|
|
|
|
192（16*12） testing areas can be set for each image；
|
|
|
|
can set multi-sensitivity (only for local channel and P6S IP camera)
|
|
|
Audio compression
|
G.711U
|
|
|
Audio output
|
HDMI, support extended audio output.
|
|
|
Audio Input
|
Can extend to 4ch audio In.
|
|
|
intercom
|
Support extend audio in and out intercom
|
|
|
coaxial audio
|
Support 4ch coaxial audio
|
|
Playback |
Video mode
|
manual>alarm>dynamic testing>timing
|
|
|
|
1CH (5MP-N coaxial input)/4CH (4MP-N coaxial input)
|
|
|
|
2CH (Coaxial or Hybrid mode);
|
|
|
|
4ch IP mode
|
|
|
|
Time retrieval, event retrieval, Timeline retrieval, channel retrieval、Face playback, Intelligent playback(Motion detection
playback) |
|
Backup |
|
1080P 10-15G/day*channel; 720P 10G/day*channel; 960H 6-10G/day*channel;
Audio:691.2M/day*channel |
|
|
Record storage
|
Local hard disk; network
|
|
|
Backup mode
|
Network backup、USB , SATA record
|
|
|
Type
|
IE/mobile/VMS
|
|
|
P2P
|
Support(IOS, Android, PC)
|
|
|
APP
|
Multi-screen surveillance; audio surveillance; mobile record; snap; pan-tile control; remote record playback
|
|
|
Camera OSD control
|
Support
|
|
|
Pan-tilt control
|
Don’t support
|
|
|
3D-NR
|
Support auto/manual setting for noise reduction parameters
|
|
|
Video input
|
8ch BNC; support coaxial audio in
|
|
|
Video output
|
1ch VGA，1ch HDMI; 1ch TV output(Optional)
|
|
|
Audio output
|
HDMI output
|
|
|
Network port
|
RJ45 10M/100M Self-adapt to Ethernet interface
|
|
|
USB port
|
2 USB 2.0 port
|
|
|
HDD port
|
1 SATA Port（Can support 8T HDD）
|
|
|
Wifi port
|
NO
|
|
|
Remote control
|
Optional
|
|
|
Power
|
12V/2A（Sufficient amperes）
|
|
|
Consumption
|
< 15W（exclusive hard disk）
|
|
|
Temperature
|
-5 °C~ +55 °C
|
|
|
Working humidity
|
10%~90%
|
Product Description
Product characteristic
1. 5 in 1 HVR product solution, supports HD analog video coding, HD analog + HD network video input, and pure HD network video input
2. Support VGA、HDMI output;
3.Support a variety of cloud technologies, realize network penetration for camera
and DVR docking, and support the functions of pushing alarm information to mobile phones
4.Support remote access, DDNS to realize one-key remote monitoring;
4.Support remote access, DDNS to realize one-key remote monitoring;
5.With UTC function, camera menu parameters can be adjusted via UTC function；
6.Support H.264/H.265(HEVC) IP camera
7.Support IP camera address modifying in bulk, and camera device added remotely；
8.Support AHD/TVI/CVI/CVBS/IP 5-in-1 and self-recognition
9.Can connect with mainstream IP camera brands in the market(private protocol or
Onvif)；
10.Support other third-party products based on ONVIF2.4 (IP mode)；
10.Support other third-party products based on ONVIF2.4 (IP mode)；
11.upport VGA、HDMI simultaneous display，Max resolution is up to HDMI 1080P.
12.Record playback can be shown by time, record type showed by color, to search
and retrieve conveniently and efficiently；
13.Record backup can be arranged according to the time and duration, accurate to
13.Record backup can be arranged according to the time and duration, accurate to
seconds；
14.Preview screen can be exchanged randomly. Picture position changed without
14.Preview screen can be exchanged randomly. Picture position changed without
physical address changing, it’s convenient for construction
15.Support multiple languages
15.Support multiple languages
16.Provide mating Web、CMS SDK service；
17.Support multiple playback modes: fast forward, slow playback, fast reverse, etc.
Max 16 times fast forward or fast reverse
18.Support WEB、VMS, support android/IOS mobile system
19.Support P2P，QR code scanning, and playback via APP
20.Support TVI coaxial audio input, and also AHD coaxial audio input.
Packing & Delivery
10PCS per Carton
FOSVISION Box packing
Port
Guangzhou
