Talents is a Chinese company that design, manufacture and supply a range of DOT 4BW 240 standard LPG gas cylinders and EN 12205 standard small brazed gas tank. Talents was founded in 1995, since then we focus on offering customers high quality, durable, applied and economic gas cylinderd. 23 years of our specialized knowledge and experience of the cylinders technology allows us to effectively supply the solutions and designing for the OEM/ODM and after-sale services of the cylinders meet our customer's needs, whilst ensuring that we are achieving maximum efficiency and output at the same time.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
TAL-P100LB-DOT
-
Brand Name:
-
talents
-
material:
-
HP325
-
Working Pressure:
-
1.6Mpa/240psi
-
Diameter:
-
375mm
-
Wall Thickness:
-
2.44mm
-
Height:
-
1255mm
-
Color:
-
Customer's Requirement
-
Certification:
-
DOT Approval
-
Standard:
-
DOT-4BW
-
Application:
-
Liqufied Propane Gas vessel
-
filling weight:
-
100lb DOT4BW lpg cylinders
Quick Details
-
Material:
-
Steel
-
Use:
-
LPG
-
Place of Origin:
-
Tianjin, China
-
Model Number:
-
TAL-P100LB-DOT
-
Brand Name:
-
talents
-
material:
-
HP325
-
Working Pressure:
-
1.6Mpa/240psi
-
Diameter:
-
375mm
-
Wall Thickness:
-
2.44mm
-
Height:
-
1255mm
-
Color:
-
Customer's Requirement
-
Certification:
-
DOT Approval
-
Standard:
-
DOT-4BW
-
Application:
-
Liqufied Propane Gas vessel
-
filling weight:
-
100lb DOT4BW lpg cylinders
Product Description
*Brief introduction of propane gas cylinder:
Propane Tanks Range in size from 5 to 100 lbs.
Used in a variety of applications - domestic, recreational, commercial, and industrial.
Conform with strict compliance to DOT specifications 4BA, 4BW,
In addition, most cylinders conform and are approved under Transport Canada specifications 4BAM, 4BWM.
Multiple testing procedures conducted for all cylinders.
Steel shot blasted prior to painting.
For maximum rust protection, all cylinders coated with Powder Coat Paint.
Capacity gauges available in 20lb, 30lb, 40lb and 100lb cylinders.
Cylinders are shrink-wrapped on pallets, or boxed individually, for protection and easy storage.
*Accumulater order plan for small order:
We can accept small quantity order, but it will take a long time. Because we need to accumulate these small orders up to the MOQ, then we will start the production line for them. Because the production cost is fixed, the small order need to bear all the cost, then price must be much higher. Through the accumulate order, you can get the cylinder at bulk order price, but you need to wait it patiently.
Used in a variety of applications - domestic, recreational, commercial, and industrial.
Conform with strict compliance to DOT specifications 4BA, 4BW,
In addition, most cylinders conform and are approved under Transport Canada specifications 4BAM, 4BWM.
Multiple testing procedures conducted for all cylinders.
Steel shot blasted prior to painting.
For maximum rust protection, all cylinders coated with Powder Coat Paint.
Capacity gauges available in 20lb, 30lb, 40lb and 100lb cylinders.
Cylinders are shrink-wrapped on pallets, or boxed individually, for protection and easy storage.
*Accumulater order plan for small order:
We can accept small quantity order, but it will take a long time. Because we need to accumulate these small orders up to the MOQ, then we will start the production line for them. Because the production cost is fixed, the small order need to bear all the cost, then price must be much higher. Through the accumulate order, you can get the cylinder at bulk order price, but you need to wait it patiently.
|
working pressure
|
1.6Mpa/240psi
|
|
Out diameter
|
375mm
|
|
height
|
1255mm
|
|
material
|
HP325
|
|
filling weight
|
100lb DOT4BW lpg cylinders
|
|
Wall thickness
|
2.44mm
|
|
Certificate
|
DOT approval
|
|
standard
|
DOT-4BW240
|
|
valve
|
CGA510 POL valve
|
|
color
|
as your requirement
|
*Valve of steel cylinder:
Overview of cylinder valve:
|
valve type
|
POL
|
OPD valve with dip tube
|
|
valve inlet
|
3/4''-14 NGT
|
3/4''-14 NGT
|
|
valve outlet
|
customized
|
customized
|
|
material
|
brass
|
brass
|
|
working pressure
|
2.2Mpa
|
2.2Mpa
|
|
pressure relief range
|
2.6-3.3Mpa
|
2.6-3.3Mpa
|
*Paint thickness and painting details
Related products
20lb propane cylinder 30lb propane cylinder 40lb propane cylinder 100lb propane cylinder
4.5kg propane cylinder 9kg propane cylinder 1lb propane cylinder 14.1oz propane cylinder
|
Lpg cylinder model
|
|
|
|
|
|
|||||
|
Lpg cylinder model
|
Water capacity (L)
|
Hight (in/mm)
|
Outside diameter (in/mm)
|
Standard
|
Working pressure (psi/Mpa)
|
|||||
|
LPG 95.4A-0
|
43.3
|
29.92/760
|
12.01/305
|
DOT-4BW240& TC-4BWM16
|
240/1.65
|
|||||
|
LPG 47.7A-0
|
21.6
|
17.99/457
|
12.01/305
|
DOT-4BA240& TC-4BWM16
|
240/1.65
|
|||||
|
LPG 118A-0
|
118
|
47.32/1202
|
15.75/400
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 52.4-0
|
52.4
|
31.81/808
|
13.19/335
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 38.1-0
|
38.1
|
26.30/668
|
12.84/326
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 35.5A-0
|
35.5
|
25.00/635
|
12.84/326
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 35.5-0
|
35.5
|
25.98/660
|
12.60/320
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 33.4-0
|
33.4
|
23.54/598
|
12.60/320
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 32.2A-0
|
32.2
|
22.72/577
|
12.37/314
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 32.2-0
|
32.2
|
23.39/594
|
12.84/326
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 31-0
|
31
|
22.99/584
|
12.84/326
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 26.2-0
|
26.2
|
23.27/591
|
11.62/295
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 23.8A-0
|
23.8
|
19.09/485
|
12.60/320
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 23.5-0
|
23.5
|
18.19/462
|
13.39/340
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 4.8C-0
|
4.8
|
11.65/296
|
7.80/198
|
DOT-4BW270
|
270/1.869
|
|||||
|
LPG 4.8B-0
|
4.8
|
12.28/312
|
8.86/225
|
DOT-4BW270
|
270/1.869
|
|||||
Our certificate
DOT/TC/TPED certificate
DOT 4BA 4BW is issued by the Department of Transportation of American(DOT)
TC 4BA 4BW is issued by the Department of Transportation of Canada(TC)
TPED certificate is for Europe market, it is also safety certificate on pressured vessel transportation
Our factory
Our Company
Talents Enterprise Company Limited
FAQ
Q: What is your Payment methods?
A: Accept paymet via T/T (Bank transfer), Western Union, Money Gram, and PayPal; Accept L/C at sight (bulk order).
Q: How long is your production time?
A: 7-10 working days for sample order; 30-40 working days for bulk order.
Q: What is the Shipping Way?
A: 30-50 days by sea to your nearest seaport 7-10 days by air to your nearest airport 5-7 days by express to your doorstep
Q: Can we have our logo or company information on the products?
A: Sure. Your Logo can show on the products by Printing, UV Varnishing, Hot Stamping, Embossing, Debossing, Silk-screen.
Q: Can you make designs for us?
A: Yes, we have professional design team. We could make designs for you as per your requests within 5days.
Q: Do you have free samples?
A: Yes, we can but you need arrange the freight charge.
