Quick Details
-
Specification:
-
200-1200mm
-
Length:
-
6m or as required
-
Thickness:
-
2-60mm
-
Standard:
-
GB/T13663-2000,ISO4427-1:2007, GB/T 13663-2000,ISO4427-1:2007
-
Color:
-
Black with bule line
-
Certification:
-
CE ISO4427-1:2007
-
Warranty:
-
50 years
-
Pressure:
-
0.6MPa
-
Product name:
-
HDPE Polyethylene Black Pipe
-
Application field:
-
Building water supply and drainage
-
Feature:
-
Corrosion Resistant
-
Usage:
-
Water Supply
-
Temperature:
-
-60℃-60℃
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hesu
-
Model Number:
-
SDR26
-
Specification:
-
200-1200mm
-
Length:
-
6m or as required
-
Thickness:
-
2-60mm
-
Standard:
-
GB/T13663-2000,ISO4427-1:2007, GB/T 13663-2000,ISO4427-1:2007
-
Color:
-
Black with bule line
-
Certification:
-
CE ISO4427-1:2007
-
Warranty:
-
50 years
-
Pressure:
-
0.6MPa
-
Product name:
-
HDPE Polyethylene Black Pipe
-
Application field:
-
Building water supply and drainage
-
Feature:
-
Corrosion Resistant
-
Usage:
-
Water Supply
-
Temperature:
-
-60℃-60℃
|
Product Name
|
PE100 Water Supply HDPE Pipe
|
|
Color
|
Black with bule line
|
|
Standard
|
GB/T13663-2000,ISO 4427-1:2007
|
|
Specification
|
20-1200mm
|
|
Pressure
|
0.6MPa SDR26,0.8MPa SDR21,1MPa SDR17,1.25MPa SDR 13.6,1.6MPa SDR 11
|
|
Main application
|
Water Supplying and Draining
|
|
Guarantee
|
More than 50 years
|
|
Pressure
OD
(mm)
|
PN0.6MPa SDR 26
Thickness
(mm)
|
PN0.8MPa SDR 21
Thickness
(mm) |
PN1.0MPa SDR 17
Thickness
(mm) |
PN1.25MPa SDR 13.6
Thickness
(mm) |
PN1.6MPa SDR 11
Thickness
(mm) |
|
63
|
|
|
3.7
|
4.7
|
5.8
|
|
75
|
|
|
4.5
|
5.6
|
6.8
|
|
90
|
|
4.3
|
5.4
|
6.7
|
8.2
|
|
110
|
4.2
|
5.3
|
6.6
|
8.1
|
10.0
|
|
125
|
4.8
|
6.0
|
7.4
|
9.2
|
11.4
|
|
140
|
5.4
|
6.7
|
8.3
|
10.3
|
12.7
|
|
160
|
6.2
|
7.7
|
9.5
|
11.8
|
14.6
|
|
180
|
6.9
|
8.6
|
10.7
|
13.3
|
16.4
|
|
200
|
7.7
|
9.6
|
11.9
|
14.7
|
18.2
|
|
225
|
8.6
|
10.8
|
13.4
|
16.6
|
20.5
|
|
250
|
9.6
|
11.9
|
14.8
|
18.4
|
22.7
|
|
280
|
10.7
|
13.4
|
16.6
|
20.6
|
25.4
|
|
315
|
12.1
|
15.0
|
18.7
|
23.2
|
28.6
|
|
355
|
13.6
|
16.9
|
21.1
|
26.1
|
32.2
|
|
400
|
15.3
|
19.1
|
23.7
|
29.4
|
36.3
|
|
450
|
17.2
|
21.5
|
26.7
|
33.1
|
40.9
|
|
500
|
19.1
|
23.9
|
29.7
|
36.8
|
45.4
|
|
560
|
21.4
|
26.7
|
33.2
|
41.2
|
50.8
|
|
630
|
24.1
|
30.0
|
37.4
|
46.3
|
57.2
|
|
710
|
27.2
|
33.9
|
42.1
|
52.2
|
|
|
800
|
30.6
|
38.1
|
47.4
|
58.8
|
|
|
900
|
34.4
|
42.9
|
53.3
|
|
|
|
1000
|
38.2
|
47.7
|
59.3
|
|
|
|
1200
|
45.9
|
57.2
|
|
|
|
Descriptions:
Meets GB/T13663-2000, ASTM D2239, ASTM D2737, ASTM D3035, ASTM F714.
Our high-density polyethylene water and sewer pipe is available in 1/2-inch to 48-inch diameters. The product's physical properties make it applicable to open-trench, horizontal directional drilling, pipe-bursting and slip-lining installations. It can be manufactured with the color striping to identify application, such as a blue stripe for potable water, a yellow stripe for gas applications and a red stripe for mining applications.
Benefits:
Our HDPE pipe for water and sewer is manufactured for excellent performance and a long life expectancy.
• Its butt-fused joints eliminate potential leak points, common at 10 to 20 feet with ductile iron pipe, for a zero leak rate.
• Highly resistant to corrosion and weather, recent studies conclude it will last at least 50 years.
• Its light weight and flexibility make it easy to install, eliminate the need for fittings required with directional changes, and make it highly suitable for use in earthquake prone areas.
• Its high-strength walls give it the highest PE pressure rating, outstanding resistance to SCG and increased resistance to rapid crack propagation.
• The increased working stress rating of high-performance PE resin material makes it a superior choice over steel or ductile iron pipe, especially for the large diameter
pipe sizes.
Application:
Hesu Pipe Industry's high-performance high-density polyethylene water pressure pipes are suitable for municipal and industrial transmission systems for potable water, sewer, drain, mining, irrigation, and reclaimed water.
