Quick Details
-
Warranty:
-
25 Years
-
Brand Name:
-
Longi
-
Model Number:
-
Longi LR5-72HBD 535-555M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm, 2278*1134*35mm
-
Product name:
-
Longi Hi-MO 5M G2 LR4-60HPH 365-385M
-
Keyword:
-
Solar Panel
-
Cell Type:
-
P-type Monocrystalline
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
Single Glass, 3.2mm Coated Tempered Glass
-
Cable:
-
4.0mm2, +400, -200mm/+-1400
-
Junction Box:
-
IP68 Rated
-
Weight:
-
32.6 kg
-
Application:
-
Commercia,Industrial,Homel
-
Certificate:
-
CE TUV
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC, Half Cell, N-TYPE
-
Panel Efficiency:
-
21.29%
-
Warranty:
-
25 Years
-
Brand Name:
-
Longi
-
Model Number:
-
Longi LR5-72HBD 535-555M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm, 2278*1134*35mm
-
Product name:
-
Longi Hi-MO 5M G2 LR4-60HPH 365-385M
-
Keyword:
-
Solar Panel
-
Cell Type:
-
P-type Monocrystalline
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
Single Glass, 3.2mm Coated Tempered Glass
-
Cable:
-
4.0mm2, +400, -200mm/+-1400
-
Junction Box:
-
IP68 Rated
-
Weight:
-
32.6 kg
-
Application:
-
Commercia,Industrial,Homel
-
Certificate:
-
CE TUV
Specification
|
Electrical Characteristics (STC)
|
|
|
|
|
|
|||||
|
Module type
|
LR5-72HBD-535M
|
LR5-72HBD-540M
|
LR5-72HBD-545M
|
LR5-72HBD-550M
|
LR5-72HBD-555M
|
|||||
|
Maximum Power-Pmax(W)
|
535W
|
540W
|
545W
|
550W
|
555W
|
|||||
|
Voltage at Pmax -Vmp(V)
|
49.35
|
49.50
|
49.65
|
49.80
|
49.95
|
|||||
|
Current at Pmax - Imp(A)
|
13.78
|
13.85
|
13.92
|
13.99
|
14.05
|
|||||
|
Open Circuit Voltage - Voc(V)
|
41.50
|
41.65
|
41.80
|
41.95
|
42.10
|
|||||
|
Short- Circuit Current - Isc(A)
|
12.90
|
12.97
|
13.04
|
13.12
|
13.19
|
|||||
|
Module Efficiency -ηm(%)
|
20.7
|
20.9
|
21.1
|
21.3
|
21.5
|
|||||
|
Weight
|
32.6kg
|
|
|
|
|
|||||
|
Size（mm)
|
2278×1134×35mm
|
|
|
|
|
|||||
|
Maximum System Voltage(V)
|
1500Vdc
|
|
|
|
|
|||||
|
Maximum Series Fuse Rating (A)
|
25A
|
|
|
|
|
|||||
