Quick Details
-
Certification:
-
CE
-
type:
-
HM
-
Remote Control:
-
434Mhz Frequency
-
Material:
-
high strong aluminum alloy
-
Function:
-
with LED light
-
Surface Treatment:
-
Powder Coating
-
Rising time:
-
6s; 4s; 1.5s
-
Model:
-
HBG-409E
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hongmen
-
Application:
-
road/high way/traffic station/parking lot
-
Certification:
-
CE
-
type:
-
HM
-
Remote Control:
-
434Mhz Frequency
-
Material:
-
high strong aluminum alloy
-
Function:
-
with LED light
-
Surface Treatment:
-
Powder Coating
-
Rising time:
-
6s; 4s; 1.5s
-
Model:
-
HBG-409E
Hongmen, with a history of 21 years, offers a lifetime warranty on the motor and 12 months on the other parts, which means that you don't need to worry about the quality or stability of our products at all.
The features
- Arm will swing out when hit directly by vehicle to avoid further damage on the vehicle.
- Once power is off, just open the cabinet and manually control the barrier by a gear mechanism. Also barrier boom can be manually locked in any position between horizontal and vertical, the lock status will remain until unlock manually.
- Using one of the best powder (Brand: Interpon), makes every colors is GREEN
- Compliance of AAMA-2603. Protection against UV, Corrosions, and Color Fading*
- The pressure wave, infrared column, loop detector and other protective devices can be added to improve safety.
Technology Data
Input Voltage | 220V± 10%, 50Hz-60Hz |
Motor Power | 100W |
Motor RPM | 1300r/min |
Operation Temperature | -30ºC to +50ºC |
Open & close time | 1.5S; 3S; 4.5S; |
IP Rating | IP44 |
Length Limit (M) | 5M |
Weight | 32kg |
Colour | Orange/white/glossy silver/ satin |
DC Brushless Motor
More stable, Noiseless operation.
Smart control panel ( Anti-smashing function from program without air sensor)
1. You can set the speed of boom (UP/DOWN), 1.5s, 3.0s and 4.5s.
2. R&D got special program for control panel, so the parking barrier got anti-smashing boom, no need to purchase air sensor.
Wireless remote control
Swing boom
1. Customized boom hand holder weaken the crush from car
2. Aluminum alloy with reflective taps and rubber tube
The Dimention
The standard package
The mass production ( Customized color for your company)
CE certification
Project Reference
