Quick Details
-
Max. Wheel Weight:
-
/, 70KG
-
Place of Origin:
-
China
-
Brand Name:
-
/
-
Model Number:
-
/
-
Warranty:
-
12 Months
-
Product Name:
-
Wheel Aligner
-
Color:
-
Red/Customized
-
Language:
-
Global Multi-language
-
Software:
-
Independent
-
Vehicle database:
-
Updated Promptly
-
Feature:
-
3D dynamic simulation
-
Turntable:
-
Included
-
Application:
-
Tire Workshop
-
Usage:
-
Car Repair Maintance Lifting
Quick Details
-
Power:
-
250w
-
Power Supply:
-
220v
-
Balancing Speed:
-
/
-
Max. Wheel Weight:
-
/, 70KG
-
Place of Origin:
-
China
-
Brand Name:
-
/
-
Model Number:
-
/
-
Warranty:
-
12 Months
-
Product Name:
-
Wheel Aligner
-
Color:
-
Red/Customized
-
Language:
-
Global Multi-language
-
Software:
-
Independent
-
Vehicle database:
-
Updated Promptly
-
Feature:
-
3D dynamic simulation
-
Turntable:
-
Included
-
Application:
-
Tire Workshop
-
Usage:
-
Car Repair Maintance Lifting
Products Description
Factory setting calibration is accurate
The equipment is calibrated before leaving the factory, and can be installed and used without re-calibration.
8 megapixels compared to low-pixel cameras, the data is more accurate and the measurement is faster.
Anti-glare high reflection material, accurate feedback signal; Internal without any electronic components, the damage rate is very low, anti-fall, anti-wear, anti-dust, more durable.
The fixture is made of light aluminum alloy material, light and labor-saving, wide size and wide applicability.
1. The positioning instrument is ≥1.2 meters away from the front end line
2. The pit depth is 5 cm
3, the cement or floor tile should be smooth, the error is not more than 5mm
4. The size range marked in the figure is the positioning area
5, the red box is the digging depth of
5 cm, the rest is cement ground
extensions:
|
Shaft offset measurement
|
Wheel offset measurement Single wheel measurement
|
|
Vehicle lift measurement
|
Steering wheel adjustment function
|
Technical Parameters:
|
Measurement items
|
Measuring range
|
measurement accuracy
|
|
Toe-in
|
±200mm
|
±0.1mm
|
|
Camber
|
+10°
|
+0.01°
|
|
Kingpin caster angle
|
±20°
|
+0.01°
|
|
thrust angle
|
30mm
|
0.1mm
|
|
direction offset
|
30mm
|
0.1mm
|
