Quick Details
-
Warranty:
-
1 years
-
Customized support:
-
Motor voltage
-
Brand Name:
-
SHUANGFA
-
Model Number:
-
YB140
-
Place of Origin:
-
Henan, China
-
Outlet Size:
-
150
-
Power:
-
15Kw, 15Kw
-
motor:
-
Famous brand motor
-
Name:
-
High Pressure Plunger Pump
-
Material:
-
Carton Steel
-
Flow rate:
-
10m3/H
-
Inlet diameter:
-
150mm
-
The height of outlet:
-
500mm
-
Dimension:
-
1550*1000*1600
-
Price of pump:
-
Cost-effective price
Quick Details
-
Application:
-
Mining industry, wastewater treatment, Water Treatment Solutions
-
Pressure:
-
High Pressure
-
Voltage:
-
380V 50Hz 3Phase, 220V/380V/440V
-
Warranty:
-
1 years
-
Customized support:
-
Motor voltage
-
Brand Name:
-
SHUANGFA
-
Model Number:
-
YB140
-
Place of Origin:
-
Henan, China
-
Outlet Size:
-
150
-
Power:
-
15Kw, 15Kw
-
motor:
-
Famous brand motor
-
Name:
-
High Pressure Plunger Pump
-
Material:
-
Carton Steel
-
Flow rate:
-
10m3/H
-
Inlet diameter:
-
150mm
-
The height of outlet:
-
500mm
-
Dimension:
-
1550*1000*1600
-
Price of pump:
-
Cost-effective price
High Pressure Plunger Pump
Features of High Pressure Plunger Pump:
1, Non metallic materials contact with food. material of sealing ring is medical polyurethane.
2, Wearable and corrosion resistance: the plungers are made of alumina ceramic firing at a high temperature.
3, Material of contact section and axle is made of stainless steel 304.
4, Big flow and high lift: Double cylinder, double acting
5, Widely used:able to deliver thick slurry suspension with high solid content
The piston pumps is widely used in conveyance of ceramic slurry, electromagnetic mud, coal slurry, kaolin, metallurgical protective material and other non-metallic pulp, metal slurry, tailing slurry, chemical pulp, electronic pulp, magnetic slurry, and food slurry, etc.
6, High working efficiency,high pressure;small pressure fluctuations;
Good wear resistance;The electricity saving effect is obvious.
7, Reliable continuous work: Using advanced commutation technique to ensure the stable performance
Details of High Pressure Plunger Pump:
Technical parameter of High Pressure Plunger Pump:
| Model | Flow(m3/h) | Pressure(Mpa) | Power(kw) |
Inlet Diameter(mm) |
Dimension(mm) |
| YB50 | 2 | 2.0 | 2.2-4 | 40 | 1200*500*1300 |
| YB85 | 3 | 2.0 | 4-5.5 | 50 | 1215*850*1500 |
| YB120 | 7 | 2.0 | 11-15 | 65 | 1550*1000*1600 |
| YB140 | 10 | 2.0 | 15-18.5 | 80 | 1550*1000*1600 |
| YB200 | 19 | 2.0 | 18.5-22 | 100 | 1700*1230*1900 |
| YB250 | 30 | 2.0 | 22-30 | 125 | 1900*1300*2000 |
| YB300 | 40-60 | 2.0 | 30-45 | 125 | 1970*1600*2100 |
| YB350 | 60-100 | 2.0 | 45-75 | 150 | 2100*1800*2300 |
Application of High Pressure Plunger Pump:
Pls Contact Us Freely for More Details!
