- Product Details
- {{item.text}}
Quick Details
-
Panel Size:
-
160x160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
led chipstar p2.5
-
Usage:
-
Indoor
-
Tube Chip Color:
-
FULL COLOR
-
Pixel pitch:
-
2.5mm
-
Module size:
-
160x160mm
-
Resolution:
-
64x64dots
-
Density:
-
160000dots/qm
-
Led Lamp:
-
SMD2121
-
Brightness:
-
800-1000cd/sqm
-
Driving method:
-
1/32 Scaning
-
Viewing angle:
-
140deg(H/V)
-
Pixel Pitch:
-
2.5mm
Quick Details
-
Application:
-
Led display
-
Brand Name:
-
JYLED
-
Color:
-
full color
-
Panel Size:
-
160x160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
led chipstar p2.5
-
Usage:
-
Indoor
-
Tube Chip Color:
-
FULL COLOR
-
Pixel pitch:
-
2.5mm
-
Module size:
-
160x160mm
-
Resolution:
-
64x64dots
-
Density:
-
160000dots/qm
-
Led Lamp:
-
SMD2121
-
Brightness:
-
800-1000cd/sqm
-
Driving method:
-
1/32 Scaning
-
Viewing angle:
-
140deg(H/V)
-
Pixel Pitch:
-
2.5mm
|
Item
|
Parameters
|
P2.5
|
|
Module
|
Module size
|
160×160mm
|
|
|
Pixel pitch
|
2.5mm
|
|
|
Pixel density
|
160000 pixels/sqm
|
|
|
Pixel configuration
|
1R1G1B
|
|
|
Package module
|
SMD2121
|
|
|
Max power consumption
|
22W
|
|
|
Module thickness
|
13mm
(without maganet)
|
|
|
Module thickness
|
26.6mm(without maganet)
|
|
|
Weight
|
0.24kg
|
|
|
Drive type
|
Constant drive
|
|
|
Scan mode
|
1/32 scan
|
|
|
Port type
|
HUB75-E
|
|
|
Brightness of white balance
|
≥1200cd/sqm
|
|
Cabinet
|
Demension
|
480×1920mm
(customized)
|
|
|
Power supply
|
5V60A
|
|
|
Best viewing distance
|
2.5-20m
|
|
|
Best viewing angles
|
(H/V):160°/120°
|
|
|
Thickness
|
65mm
|
|
Power
|
Working voltage
|
AC 220V ±10%
|
|
|
Average power consumption
|
233W/sqm
|
|
|
Max power consumption
|
≤700W/sqm
|
|
|
Current
|
≤20mA(single LED)
|
Wooden case
Flight case
Q1:Are you a Factory or trading company?
We are factory.We have our sales team of International trade.
Q2: When will the products be delivered if the order has been placed?
For normal products,it will take less than 1week to produce,for customized products it will take 6~8 days for production.
Q3: What is your quality control process?
We do 100% testing for any of products before the order has been delivered.
Q4: Do you have quality gurantee?
Yes, we do 1 Year Warranty for any of our products.
Q5: What about the payment?
We accept T/T, and L/C for the la
rge quantities order, and Western
union and Moneygram will be accept for the small quantities order.
