Quick Details
-
Scan Speed:
-
200±2/s
-
Brand Name:
-
Zhaohe
-
Place of Origin:
-
Guangdong, China
-
Type of light source:
-
white LED
-
Scanning accuracy:
-
3ML(0.0726MM)
-
Scanning method:
-
Auto-sensing
-
Dimensions:
-
156*95*96mm
-
Voltage:
-
5V/400mA
-
Operating temperature:
-
-20℃-50℃
-
humidity:
-
5%-95%
-
CPU:
-
RAM:32 bit
-
Scan angle:
-
Rotation angle ±360°Elevation angle ±65°Deflection angle ±65°
-
Bit error rate:
-
1/50 million
Quick Details
-
Type:
-
PORTABLE
-
Scan Element Type:
-
CCD
-
Optical Resolution:
-
Standard Range(SR) 1D Linear,0.102mm/4miles,
-
Scan Speed:
-
200±2/s
-
Brand Name:
-
Zhaohe
-
Place of Origin:
-
Guangdong, China
-
Type of light source:
-
white LED
-
Scanning accuracy:
-
3ML(0.0726MM)
-
Scanning method:
-
Auto-sensing
-
Dimensions:
-
156*95*96mm
-
Voltage:
-
5V/400mA
-
Operating temperature:
-
-20℃-50℃
-
humidity:
-
5%-95%
-
CPU:
-
RAM:32 bit
-
Scan angle:
-
Rotation angle ±360°Elevation angle ±65°Deflection angle ±65°
-
Bit error rate:
-
1/50 million
1.Specification
| Part No. | ZH-QS10 |
| Type of light source | White LED |
| Scan mode | CCD |
| Support interface | USB |
| Scanning method | Auto-sensing |
| Dimensions | 156*95*96mm |
| Net weight | 0.365KG |
| Voltage | 5V/400mA |
| Operating temperature | -20℃-50℃ |
| humidity | 5%-95% |
| Vibration resistance | Can fall from a free fall of 1 meter in the air |
| CPU | RAM:32 bit |
| Plus speed | 200±2/s |
| Scan angle | Rotation angle ±360°Elevation angle ±65°Deflection angle ±65° |
| Bit error rate | 1/50 million |
| Prompt method | Buzzer, indicator light |
| Storage temperature | -40℃-60℃ |
| Ambient brightness | 3000-8000LUX(sunlight) |
| Dustproof | Sealed, can resist air dust from entering |
| Decoding type | UPC-A, UPC-E, EAN-13, EAN-8, ISBN/ISSN/, code 39, code 39 (ASCII full code), code 32, TRIOPTIC code 39, cross code, industrial code 25, matrix code 25, NW7 , Code 128, code 98, code 11 (USD-8), MSI/PLESSEY, UK/PLESSEY, UCC/EAN 128, China post code, GS1 DATABA series |
Shenzhen Zhaohe Technology Co., Ltd
• Main information:
1.Established in 2013
2.Headquartered in Longhua,Shenzhen,China,
3.ODM/OEM manufacturer
• Introduction
Zhaohe is a professional ODM/OEM manufacture which engaged in R&D, manufacturing, sales, service of high-quality touch screen POS terminals, all-in-one POS, Portable POS, printer and commercial display field.
Our products are widely used in department stores, supermarkets, specialty stores, conveniences stores, boutiques, restaurants, hotels and other corporate units.
We have a professional technical talent team engaged in hardware design and software development.
If you are interested in any of our products or would like to discuss a custom order, please contact us.
1. Are you a manufacturer?
Yes. We are a professional pos system and advertising screen hardware manufacturer based in Shenzhen, China.
2 . Can I get some samples? Are they free?
Of course, you can get sample for testing before bulk order, but samples are not free. But the cost can be refundable after mass order.
3. What are your payment terms?
We accept T/T,Trade Assurance Order or Paypal payment terms.You can choose the payment terms which convenient to you.
4. What's the delivery time?
Most of the products are in stock. We can send to you within 2-3 working days after your payment .
for the products are out of stock; delivery time base on order quantity.
5. What about the warranty time?
We provide 1 year warranty for all our product .
6. Can I have my own logo on the products, do you offer product OEM?
Yes! We can put your logo on the product and we do OEM for customers. But it requires a certain quantity and the cost need to be added separately.
7. What kind of certificate y ou have?
CE, FCC and RoHS as standard.Some products approved EMv&PCI,CB,CCC certificates.
8. Do you provide software?
As a hardware producer, We suggest you to get software in local because of the using habit.
9. What about the after-sale service ?
We provide full technical support on our products, if there is a machine doesn’t work, a free parts will be sent to you by free to replace, if it still not working, we will send you a new one.
