Quick Details
-
Output:
-
21V/60A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Quawin/OEM
-
Model Number:
-
QW185-600-LC
-
Output Power:
-
1500W
-
Input:
-
180-264VAC 50/60Hz with PFC
-
Efficiency::
-
>=90%
-
Charge mode::
-
CC---CV---Float Charge
-
Output voltage:
-
21V
-
Output current:
-
60a(Max)
-
Output power:
-
1,260W
-
Additional features:
-
CANBUS Protocol
-
Dimensions (mm):
-
314*138*86
-
Weight:
-
3700±50g(only body)
-
Warranty:
-
24 Months
Quick Details
-
Type:
-
Desktop
-
Use:
-
Standard Battery, scooter, PROFESSIONAL, Industrial, electric car, electr bike, electric motorcycles, IoT devices, Energy storage systems, Solar and wind energy systems, Logistics vehicles, Smart home systems, Medical device charging, Industrial robots
-
Is LED Lamp Illumination:
-
NO
-
Output:
-
21V/60A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Quawin/OEM
-
Model Number:
-
QW185-600-LC
-
Output Power:
-
1500W
-
Input:
-
180-264VAC 50/60Hz with PFC
-
Efficiency::
-
>=90%
-
Charge mode::
-
CC---CV---Float Charge
-
Output voltage:
-
21V
-
Output current:
-
60a(Max)
-
Output power:
-
1,260W
-
Additional features:
-
CANBUS Protocol
-
Dimensions (mm):
-
314*138*86
-
Weight:
-
3700±50g(only body)
-
Warranty:
-
24 Months
Quick Detail:
Brand Name:QUAWIN
Model Number:QW185-600-LC
Use:5S 18V 18.5V Li-ion or Li-polymer battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 21V
Color:Black/Army green
Shell Material:Aluminium alloy
Additional functionality:LED display
Additional features:CANBUS communication protocol
Input voltage:AC 180~264V 50/60Hz With PFC
Output voltage:21V
Output current:60a(Max)
Output power:1,260W
Charge mode:CC—CV(Constant Current—Constant Voltage)
1500W Certification:CE
Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized
Packaging & Delivery:
Inner package:Corrugated box,EPE pearl cotton/according to your requirements
Outer packing: export carton
Delivery Detail:sample within 7 work days,25-35 days for bulk order
Specifications:
5S 18V 18.5V Li-ion or Li-polymer battery pack
Features:
• Charging mode:CC—CV(Constant Current—Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=90%
• Operating temperature:-20℃ ~ 45℃
• Storage temperature:-40℃ ~ 85℃
• Operating humidity:5%~90%RH
Safety protections:
• Input: AC 180~264V 50/60Hz With PFC
• Output: DC 21V
• Charging current: 60a(Max)
• Dimensions (mm): 314*138*86
• Weight:3700±50g(only body)
Safety protections:
• Over current protection
• Over voltage protection
• Short circuit protection
• Reverse polarity protection
• Anti-revert current protection
• Anti-spark protection
LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Waiting Mode:LED(GREEN) ON
•
Charging Mode:LED(BLUE) FLASH
•
Full Charged Mode:LED(GREEN) ON
•
Charge Error Mode:LED(RED) FLASH
Call us to know more details datasheet.
|
Typical Product Model |
|||||
|
Model |
Input Voltage
|
Battery Voltage
|
Charging Voltage
|
Charging Current
|
|
|
QW128-600-FC |
LiFePO4 |
AC 180~264V |
12.8(4S) |
14.6 |
60 |
|
QW256-500-FC |
25.6(8S) |
29.2 |
50 |
||
|
QW384-300-FC |
38.4(12S) |
43.8 |
30 |
||
|
QW512-250-FC |
51.2(16S) |
58.4 |
25 |
||
|
QW640-200-FC |
64(20S) |
73 |
20 |
||
|
QW768-150-FC |
76.8(24S) |
87.6 |
15 |
||
|
QW148-600-LC |
Lithium |
14.8(4S) |
16.8 |
60 |
|
|
QW259-500-LC |
25.9(7S) |
29.4 |
50 |
||
|
QW370-300-LC |
37(10S) |
42 |
30 |
||
|
QW481-250-LC |
48.1(13S) |
54.6 |
25 |
||
|
QW629-200-LC |
62.9(17S) |
71.4 |
20 |
||
|
QW740-150-LC |
74(20S) |
84 |
15 |
||
