Quick Details
-
Type:
-
Prefabricated Modular Houses
-
Size:
-
20FT/40FT Customized
-
Usage:
-
Workshop Warehouse Construction Office
-
Transport and load:
-
40HQ Container
-
Keyword:
-
Prefab Modern Homes
-
Main structure:
-
Galvanized Light Steel Frames
-
Certification:
-
CE Certification
-
Advantage:
-
Environmental Protection Low Cost Recycle
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
CDPH
-
Product name:
-
expandable house 40 foot container with 3 bedroom
-
Type:
-
Prefabricated Modular Houses
-
Size:
-
20FT/40FT Customized
-
Usage:
-
Workshop Warehouse Construction Office
-
Transport and load:
-
40HQ Container
-
Keyword:
-
Prefab Modern Homes
-
Main structure:
-
Galvanized Light Steel Frames
-
Certification:
-
CE Certification
-
Advantage:
-
Environmental Protection Low Cost Recycle
PRODCUT DESCRIPTION
|
Technical Parameter of Expandable Container
（Export standard configurations）
|
|
|
||
|
Basic features
|
External dimension (mm)
|
6320*5900*2480
|
||
|
|
Internal dimension(mm)
|
6160*5560*2240
|
||
|
|
Folding state(mm)
|
2200*5900*2480
|
||
|
|
Total mass（kg）
|
|
||
|
Frame structure
|
Middle roof beam
|
T2.5mmQ235B
|
||
|
|
Middle base beam
|
T2.5mmQ235B
|
||
|
|
Side beam
|
t1.5mmQ235B
|
||
|
|
Middle pillar
|
T2.5mmQ235B
|
||
|
|
Side wall frame
|
t1.5mmQ235B
|
||
|
|
Sub-frame
|
t1.5mmQ235B
|
||
|
|
Hanging head
|
t4mmQ235B
|
||
|
|
Folding hinge
|
13mm Galvanized hinge
|
||
|
|
Protective coating for integral frame
|
Electrostatic spraying/Straight white plastic powder
|
||
|
|
Top and bottom of middle cabinet
|
80*100
|
||
|
|
Top and bottom of side cabinet
|
40*60*1.5 thick square tube
|
||
|
Top of container
|
External roof board
|
t0.5mm Galvanized plate
|
||
|
|
Internal ceiling board
|
t831 internal ceiling board
|
||
|
Wall panel
|
Heat preservation of middle top
|
T50mm glass filament cotton（Side top 50 foam plate)
|
||
|
|
Side wall, front wall panel& back wall panel
|
t50mm-Color steel plate with glass filament cotton or t50mm-Foam plate
|
||
|
|
Internal partition
|
t50mm Foam board
|
||
|
|
Internal washroom
|
About 1700*1500mm (can be adjusted)
|
||
|
Floor
|
Middle floor
|
Fireproof glass magnesium floor 15mm
|
||
|
|
Floor on both sides
|
Bamboo flooring
|
||
|
Electrical system
|
Electrical wiring, install in strict accordance with the moisture-proof specifications, all electrical products shall comply with CE certification. Connect the circuit according to the circuit engineering specification, indoor：2 LED lights, 2 Ceiling lamp, 3 five- hole single socket, 1 single switch, 3 ten -hole socket，1 Air conditioner socket，1 20A -Leakage protector.
Voltage 220V, 50HZ |
|
||
|
Common Security Door
|
2 sets of Common security door
|
|
||
|
Window
|
4 sets of Sliding plastic steel single glass window （920*1120mm）
|
|
||
|
Quality guarantee
|
1 year
|
|
||
